Liquid-Cooled 832V 261KWh BATTERY LiFePO4 BESS System for Industrial Commercial
Liquid-Cooled 832V 261KWh BATTERY LiFePO4 BESS System for Industrial Commercial
Liquid-Cooled 832V 261KWh BATTERY LiFePO4 BESS System for Industrial Commercial
Liquid-Cooled 832V 261KWh BATTERY LiFePO4 BESS System for Industrial Commercial
Specifications
Brand Name :
JUNEXT
Model Number :
JNESS0261-0125B
Certification :
UN38.3、MSDS、CE、
Place of Origin :
shenzhen
Description
832V DC Liquid Cooled Battery Energy Storage Unit 261KWh Rated Energy for Sustainable Energy Solutions
Product Parameters
Liquid-Cooled 832V 261KWh BATTERY LiFePO4 BESS System for Industrial CommercialLiquid-Cooled 832V 261KWh BATTERY LiFePO4 BESS System for Industrial CommercialLiquid-Cooled 832V 261KWh BATTERY LiFePO4 BESS System for Industrial Commercial
Specifications
Model JNESS0261-0125B
Dimension(LxWxH) 1000x1300x2200mm(Ring hanger is not included)
Weight 2850kg士100kg
Series-parallel Mode 1P260S
Nominal Voltage DC:832V
Rated Capacity 314Ah
Rated energy 261.25KWh
Operating Voltage DC:650V~949V
Max Current 200A(DC side)
Overall Efficiency >88%@25℃士2℃,0.5P
Cycle Life ≥8500 Cycle @25℃士2℃,0.5P,70%SOH
IP Grade IP54
AC grid-connected
Nominal Voltage AC:400V(-10%~+15%)
Max Current AC:180A
Rated power 125kW@25℃士2℃
Maximum Sustained Power 137.5kW@25℃±2℃
Rated grid frequency 50Hz/60Hz
Off-grid output THDU <3%(linear load)
Nominal Voltage (3W+N+PE)Three phase four wire
AC Off-Grid
Max Voltage AC:400V
Max Current AC:180A
Rated power 125kW@25°C
Rated frequency 50Hz/60Hz
Liquid-Cooled 832V 261KWh BATTERY LiFePO4 BESS System for Industrial CommercialLiquid-Cooled 832V 261KWh BATTERY LiFePO4 BESS System for Industrial CommercialLiquid-Cooled 832V 261KWh BATTERY LiFePO4 BESS System for Industrial Commercial
