660 Channels Smart Hi-Target GPS Surveying Instrument V200 Gnss Rtk with Ihand55 Controller
660 Channels Smart Hi-Target GPS Surveying Instrument V200 Gnss Rtk with Ihand55 Controller
660 Channels Smart Hi-Target GPS Surveying Instrument V200 Gnss Rtk with Ihand55 Controller
660 Channels Smart Hi-Target GPS Surveying Instrument V200 Gnss Rtk with Ihand55 Controller
660 Channels Smart Hi-Target GPS Surveying Instrument V200 Gnss Rtk with Ihand55 Controller
660 Channels Smart Hi-Target GPS Surveying Instrument V200 Gnss Rtk with Ihand55 Controller
660 Channels Smart Hi-Target GPS Surveying Instrument V200 Gnss Rtk with Ihand55 Controller
660 Channels Smart Hi-Target GPS Surveying Instrument V200 Gnss Rtk with Ihand55 Controller
Specifications
Brand Name :
Hi-Target
Model Number :
V200
Place of Origin :
China
MOQ :
1
Price :
$1,399.00-$1,999.00 1 -5 pieces
Supply Ability :
1000 pieces
Delivery Time :
3-5 work days
Packaging Details :
Original packaging box
Description

Basic Info.

Model NO.
V200
Channel
660
Tilt Survey
Support
External Radio
30W
Transport Package
Carton
Specification
30kg
Trademark
hi-target
Origin
China
HS Code
8526919090
Production Capacity
4000/Year

SPECIFICATIONS

V200 specification
Channels 800+
Satelite Tracked GPS:L1/ L2/ L5/L2C
BeiDou:B1/ B2/ B3/B1C/B2a
GLONASS: L1/L2/L3
Galileo:E1/ E5 AltBOC/E5a/E5b/E6
QZSS:L1/L2/L5/L6
SBAS: L1/ L5
IRNSS:L5
Static and Fast static Gnss Surveying
Horizontal ± (2.5+0.5× 10-6d) mm (D is the distance between measured points)
Vertical ± (5+0.5× 10-6d) mm (D is the distance between measured points)
Post Processing Kinematic (PPK / Stop & Go ) GNSS Surveying
Horizontal 8mm+1ppm RMS
Vertical 15mm+1ppm RMS
Initialization time Typically 10 min for base while 5 min for rover
Initialization reliability typically > 99.9%
High-precision static GNSS Surveying
Horizontal ±(8+1×10¯6D)mm (D is the distance between measured points)
Vertical :±(15+1×10¯6D)mm D is the distance between the measured points
Code Differential GNSS Positionnig
Horizontal ±0.25m + 1 ppm RMS
Vertical ±0.25m + 1 ppm RMS
SBAS
Positioning accuracy 0.50m Horizontal, 0.85m Vertical
Real Time Kinematic (RTK)
Single Base Horizonta:8mm+1ppm RMS
Vertica:15mm+1ppm RMS
Network RTK Horizonta:8mm+0.5ppm RMS
Vertical:15mm+0.5ppm RMS
Initialization time:Typically <10s
Initialization reliability:Typically > 99.9%
Communication
Internal UHF Radio Frequency: 410-470MHz
Channels:116 (16 adjustable)
Transmitting power:0.5W,1W,2W
agreement:Hi-Target, Trimtalk450S, trimmarkIII, Transeot, SATEL-3AS,South,CHC,ect
Working Range:3-5km typical, 8-10km optimal
HI-TARGET External UHF Radio(Standard) Frequency: 403-473MHz
Transmitting speed:Up to 19.2Kbps
Channels:116 (16 adjustable)
5W,10W,20W,30W adjustable
Working Range:8~10km typical,15~20km optimal
IMU(Tilt Survey) Built-in high-precision inertial navigation, automatic attitude compensation, no correction, anti-magnetic interference, instant measurement at the point of arrival;
Network Communication
Full band support for cellular mobile network(LTE, WCDMA, EDGE, GPRS, GSM) 2.4GHz WIFI, supports 802.11b/g/n. Network RTK (in CORS) range is 20-50km
Physical
Dimensions(W×H) 132mm*67mm
Weight ≤0.83kg (includes battery)
Shock and vibration Designed to survive a 2m(9.84ft) natural fall onto concrete
Water/Dustproof IP67
Humidity 100% condensing
Operation temperature -30ºC~+70ºC
Storage temperature -40ºC~+80ºC
Bluetooth 2.1+4.0
NFC NFC flash even
A serial port RS232 serial port
Control Panel Physical button
Energy consumption and working hours
Electrical Power 6V to 28V DC external power input
Power consumption≤4.2W
Built-in high-capacity lithium battery 6800mAh/7.4V, support USB PD3.0 super fast charging, charging time <3.5h
Internal Battery Life Static more than 10 hours
RTK rover (UHF/GPRS/3G)6-10 hours
RTK base more than 10 hours
