Zeiss CMM Straight Gear Transmission Idler Gear Tooth Weight 4.66kg 24.3 Width
Zeiss CMM Straight Gear Transmission Idler Gear Tooth Weight 4.66kg 24.3 Width
Specifications
Brand Name :
WINNER
Certification :
IATF16949
Place of Origin :
TAIZHOU-CHINA
MOQ :
5000
Price :
CNY+100-400+YUAN
Payment Terms :
T/T, MoneyGram
Supply Ability :
1200+SET+DAY
Delivery Time :
5-8 workdays
Packaging Details :
According to customer's requirement
number of teeth :
16
tooth depth :
5.34
tooth width :
24.3
weight :
4.66kg(rough turning state）
material :
ZF7B
gear surface hardness :
≤230HB
materials :
transmission structural steel
application :
AT transmission components
Description

The Idling gear checkout equipment is Mitoyo contourgraph and tooth weight of 4.66kg, The hardness of the product is required to be ≤230HB, there are many hardness classification, among them, brinell hardness is determined by the depth of indentation plastic deformation hardness index.


Barcol hardness, first proposed by The American Barber-Colman Company, is a kind of hardness category widely used internationally in modern times. A hard steel pressing needle of a certain shape is pressed into the sample surface under the action of standard spring test force, and the material hardness is determined by the pressing depth of the pressing needle. A unit of Barb hardness is defined as 0.0076mm per injection. The unit of Barb hardness is HBa.

Product specification:

number of teeth 16
tooth depth 5.34
tooth width 24.3
weight 4.66(rough turning state)
material ZF7B
gear surface hardness ≤230HB
application AT transmission components
product description: for power transmission purposes and parking.
materials transmission structural steel
processing technic
forging+machine work
fabricating machinery mechanical press+CNC Lathe+machining center
checkout equipment Klingberg Gear Btesting Center+Zeiss CMM+Mitoyo contourgraph

Zeiss CMM Straight Gear Transmission Idler Gear Tooth Weight 4.66kg 24.3 WidthZeiss CMM Straight Gear Transmission Idler Gear Tooth Weight 4.66kg 24.3 WidthZeiss CMM Straight Gear Transmission Idler Gear Tooth Weight 4.66kg 24.3 Width

Related products:

automatic transmission components
auto transmission parts
idle gear
transmission gear
idler gear
spur gear transmission
transmission gear parts
straight gear transmission
output shaft gear
gear forging process
gear tooth width
alloy steel gear
gear drive engine

FAQ:

Q: Can you send me a sample?

A: Yes, we can send you the sample to check the quality, but you need to pay all the cost of the sample.

Q: How to get the best price?

A: You can consult our commercial department for pricing.

Q:What are your packing terms?

A: Generally speaking, we will pack properly according to your requirements.

Q:What are your terms of payment?

A:generally speaking, telegraphic transfer 30% serves as deposit, 70% is before deliver, but specific circumstance, want to seek advice from our business branch, according to different actual situation, differ somewhat.
