Single Dual Row 2.54mm Pitch Machined Surface Mount 4 Pin Female Header 2.54PH
Single Dual Row 2.54mm Pitch Machined Surface Mount 4 Pin Female Header 2.54PH
Specifications
Insulation Material :
Black PPS
Pitch :
2.54 mm
Type :
SMT
Gender :
Female
Brand Name :
Jrkconn
Model Number :
JRK-NNN1-BPP0743AD
Certification :
ISO9001, ISO14001
Place of Origin :
Guangdong , China
MOQ :
500PCS
Price :
Contact us
Payment Terms :
T/T
Supply Ability :
10000000 per week
Delivery Time :
7-15 working days
Packaging Details :
Tube+carton box packing
Contact material :
Brass
Durability :
500 cycles
Series :
Socket Connector
NO. of Contacts :
1-40
Description
Single Dual Row 2.54mm Pitch Machined Surface Mount 4 Pin Female Header 2.54PH
Product Overview

Single Dual Row Machined Round Female Header Connector Surface Mount 2.54PH. These machined female header connectors, also known as PCB connectors or socket connectors, are designed for surface mount applications and work in conjunction with corresponding male connectors to facilitate circuit connections.

Technical Specifications
Insulation MaterialBlack glass-filled polyester PPS + GF30
FlammabilityUL94V-0
Model No.JRK-NNN1-BPP0743AD
Pitch2.54mm / special pitch (optional), support custom
RowSingle row
Contacts1 to 40 Contacts
ColorBlack, support custom
Terminal MaterialBrass CuZn36Pb3 (C36000)
Contact Clip MaterialBeryllium copper (C17200)
Plating (outer sleeve)Tin plated: 2µm/80µ"Ni, 5µm/200µ"Sn, Gold plated: 2µm/80µ"Ni, Full gold
Plating (contact clip)2µm/80µ"Ni, Gold or Tin plated
Contact Resistance≤4mΩ/Contact
Rating Current3 A
Mechanical LifeMin. 500 cycles
Insulator Resistance≥1000MΩ at V=100V
Operating Voltage60VAC/DC
Operating TemperaturesGold Plated: from -55°C to 105°C, Tin plated: from -40°C to 105°C
Packing & Delivery
Packing Information
Selling unitsSingle item
PackageTube / PE bag/ tray / tape&reel packing
PortShenzhen
Delivery Timeline
Quantity (pcs)1 - 100K> 100K
Estimated delivery time (business day)15To be negotiated
Custom Process
Single Dual Row 2.54mm Pitch Machined Surface Mount 4 Pin Female Header 2.54PH
Our Advantages
  • Extensive connector options and customized services
  • Free samples with 3-7 working days delivery
  • High quality with competitive pricing
  • Low MOQ and fast lead time
  • High efficiency, professional service with responsibility and passion
  • Provide one-stop solution
How To Choose A Machined Female Header Connector

Please provide the following information for customization:

  • The pitch of the product (e.g., 1.27mm, 2.0mm, 2.54mm, or special pitch)
  • The material of the insulator, outer sleeve, and contact clip
  • The plating requirements for outer sleeve and contact clip
  • Your order quantity and specific requirements
Frequently Asked Questions
Are you a manufacturer or trade company?

We are a professional manufacturer with 15 years of experience specializing in electronic connectors. Our main products include pin headers, female headers, box headers, ejector headers, DIN41612 connectors, pins, and other electronic connectors.

Can I get samples before placing an order?

Yes, we provide samples for quality verification. Free samples (1-2 pcs) are available with customers only paying express courier costs.

What is the sample lead time?

Standard samples: 3-5 working days. Customized samples: 7-10 working days.

What is your after-sales service?

If quality issues arise, contact us for prompt investigation and solutions.

How do you guarantee product quality?

Pre-production samples before mass production and final inspection before shipment.

Can I order personalized/customized products?

Yes, please send us your drawing or sample for customization.
