Compliant with GJB599B (MIL-DTL-38999M) Series II standard. Adopts card-type quick connection design. It features the smallest volume, lightest weight and shortest housing length among all 599 series products.

It provides excellent EMI/RFI shielding performance. The contacts are press-fit and detachable with anti-diagonal insertion structure. For limited space where plugging and unplugging is inconvenient, it is recommended to pre-install pins into the socket.

Purpose: This product is used for circuit signal connection.

Application environment: This lightweight electrical connector is suitable for occasions without high-intensity vibration, severe wind, sand and humid harsh conditions.

Mechanical Properties:
Shell Material: Aluminum alloy, Stainless steel

Coating:
Class B: Mili-tary green cadmium plating
Class E: Stainless steel passivation
Class F: Electroless nickel plating

Contact: Gold-plated copper alloy surface, suitable for crimping, welding and PCB mounting

Mechanical lifespan: 500 mating cycles

Vibration: Random vibration; frequency 100–1000 Hz, power spectral density 1 g²/Hz

Impact: 3 ms half-sine wave; peak acceleration 300g

Contact resistance and rated current of the contact parts:

Electromagnetic interference shielding: at 100 MHz-1 GHz, minimum attenuation is 45 dB; Withstand voltage:V

Insulation resistance: Under normal conditions ≥ 5000 MΩ

Electrical continuity between the shell and interior: Class B ≤ 2.5 m Ω

Moisture condition: ≥ 100 M Ω

F class ≤ 1.0 m Ω E class ≤ 50 m Ω

Operating Temperature:Class B: --65 ˚ C ~ +175 ˚ C; Class E and F: --65 ˚ C ~ +200 ˚C;

Salt Spray Resistance:Class B:500h; Class E:1000h Fcategory:48h

Relative humidity: At 40 ˚ C, it reaches 98%

Working height: ≤ 30480 m
