Every Johnson water well drilling project is different and the operator has to use different well-completion tools to ensure maximum production without increasing the costs. We produce a wide range of well-completion accessories and sand control screens.

Well-completion equipment is essential in ensuring the oil well productivity is as efficient as possible. This is why we produce a wide selection of crossovers and couplings. What's more, we also produce mule shoes, wire line entry guides, flow couplings, blast joints, and much more.

Completion Products is one of the world's leading sand control screen suppliers worldwide. We produce and sell premium oil & gas well screens, sand control screens, direct wrap screens, wire wrapped screens, water well screens, and repack screens. Our sand screen is patented and has obtained awards and certifications.

Thanks to our premium sand screen, we're one of the best sand screen manufacturers in the world. Our premium sand screen utilizes the principles of Direct Wrap and swaging to eliminate gaps between layers so it can deliver expected mechanical properties while providing a high flow and open area for sand control performance.

Name: Johnson Water Well Screens, Johnson Sand screen, Continuous Slot Water Well Screen, Water wire screen, Wedge wire screen, Screen tube, Slotted tube, Wound screen, Continuous slot screen filter, Sand control screen, Wedge wire screen pipe, Rotary filter drum, Oil screen.

Material: Stainless steel 202, 304, 304L, 316L, Non-magnetic Stainless steel, Low carbon galvanized etc.

Diameter: 3", 4", 6", 8", 10", 12", 14", 16", 18" etc.

Slot: From 0.1-100mm (Normal slot 0.5mm, 0.63mm, 0.75mm, 1.0mm, 1.5mm)

Length: From 100-6000mm (Normal length is 2.9m/3m and 5.8m/6m, to fit container)

Wrap wire: 2*3.5mm, 2.2*3.5mm, 3*4.6mm, 3*5mm, 3*6mm, 3*6.5mm, 3.2*6mm, 4*7mm etc.

Support rod: ø3.0-ø6.0mm round wire, Also can be Vee-shaped wire.

Ends: Welded rings/Plain beveled ends, Male/female threaded, Flange etc.

Use: Water Well, Oil Wells, Waste Water Treatment, Water supply systems, Coal & Mine, Food Processors & Beverage Screens, Environmental protection, Refining & Petrochemical, Architecture & Construction etc.

Special specification can be made according to your need!

• Sand analysis of formation materials
• Screen size recommendations
• Screen installation suggestions
• Well construction consultation

Our technical staff includes expert design engineers, welders, technical support personnel, and sales engineers who are familiar with all aspects of manufacturing and deployment of downhole screens for different applications.
