Specifications
Brand Name :
Heng Yuan
Model Number :
12-3/4" 10-3/4" 8-5/8" 6-5/8"
Certification :
ISO9000
Place of Origin :
Hengshui,Hebei,China
MOQ :
1pcs
Price :
Negotiation
Payment Terms :
L/C,L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
1000pcs/Month
Delivery Time :
10 work days
Packaging Details :
Plastic film
Name :
Wire Wrapped Screen
Material :
Stainless steel and low carbon steel
Diameter :
114-500mm
Length :
upto 6000mm
Slot size :
0.05-100mm
Wrap wire :
1.5*2mm, 2*3mm, 2*3.5mm, 2.2*3.5mm,3*5mm
Support rod :
ø4.0mm and others
End connection :
male/female threaded
Package :
Plastic film
Use :
In water wells for sand control
Description
Johnson Vee-Shaped Wire Wrapped Screen Machine
Johnson Vee-Shaped Wire Wrapped Screen Specifications
Attribute Value
Name Johnson Vee-Shaped Wire Wrapped screen
Material Stainless steel and low carbon steel
Diameter 114-500mm
Length upto 6000mm
Slot size 0.05-100mm
Wrap wire 1.5*2mm, 2*3mm, 2*3.5mm, 2.2*3.5mm, 3*5mm,3*6mm
Support rod ø4.0mm and others
NO. of rods we will make it according to the diameter
End connection Male/female threaded, welded rings
Surface Polished
Package Plastic film
Use In water wells for sand control
Johnson Vee-Shaped Wire Wrapped Screen Specifications

Name: Wire-Wrap screen, Continuous Slot Water Well Screen, Johnson screen, Water wire screen, Wedge wire screen, Screen tube, Slotted tube, Wound screen, Continuous slot screen filter, Sand control screen, Wedge wire screen pipe, Rotary filter drum, Oil screen.

Material: Stainless steel 202, 304, 304L, 316L, Non-magnetic Stainless steel, Low carbon galvanized etc.

Diameter: 3", 4", 6", 8", 10", 12", 14", 16", 18" etc.

Slot: From 0.1-100mm (Normal slot 0.5mm, 0.63mm, 0.75mm, 1.0mm, 1.5mm)

Length: From 100-6000mm (Normal length is 2.9m/3m and 5.8m/6m, to fit container)

Wrap wire: 2*3.5mm, 2.2*3.5mm, 3*4.6mm, 3*5mm, 3*6mm, 3*6.5mm, 3.2*6mm, 4*7mm etc.

Support rod: ø3.0-ø6.0mm round wire, Also can be Vee-shaped wire.

Ends: Welded rings/Plain beveled ends, Male/female threaded, Flange etc.

Use: Water Well, Oil Wells, Waste Water Treatment, Water supply systems, Coal & Mine, Food Processors & Beverage Screens, Environmental protection, Refining & Petrochemical, Architecture & Construction etc.

Sizes (inch) OD (mm) Slot (mm) Length (m) Tensile Strength Collapse Strength Wrap wire Vee-shaped wire (mm) Support rod Round wire (mm)
3-1/2 88.9 1.0 2.9 ＞22 10.2 2.0*3.5(Width*height) ø3.8MM×22
4-1/2 114.3 1.0 2.9 ＞28 11.5 2.0*3.5(Width*height) ø3.8MM×22
6-5/8 168.3 0.75 5.8 ＞40 12.8 2.0*3.5(Width*height) ø3.8MM×32
6-5/8 168.3 1.0 5.8 ＞33 12.8 2.2*3.5(Width*height) ø3.8MM×32
6-5/8 168.3 0.63 5.8 ＞83 45 3.0*6.0(Width*height) ø6.0MM×32
8-5/8 219.1 1.0 5.8 ＞34 21.9 2.2*3.5(Width*height) ø3.8MM×48
8-5/8 219.1 1.0 5.8 ＞50 38.2 3.0*4.6(Width*height) ø4.0MM×48
8-5/8 219.1 1.0 5.8 ＞60 46 3.0*6.0(Width*height) ø5.0MM×48
10-3/4 273.1 0.75 5.8 ＞50 32.9 2.2*3.5(Width*height) ø4.0MM×55
10-3/4 273.1 1.0 5.8 ＞60 39.5 3.0*4.6(Width*height) ø4.8MM×55
10-3/4 273.1 1.0 5.8 ＞100 48 3.2*6.0(Width*height) ø5.0MM×55
12-3/4 323.9 1.0 5.8 ＞120 37.2 3.0*5.0(Width*height) ø4.0MM×56
14 355.6 1.0 2.9 ＞80 37.8 3.0*5.5(Width*height) ø4.0MM×59
16 426 1.0 2.9 ＞80 37.5 3.0*5.5(Width*height) ø4.0MM×64

Special specification can be made according to your need.
