Cylindrical Vee Shaped Wire Wrapped Screen With High Abreaction Resistance

Product Description:

Wire Wrap Screen is manufactured with Vee-shaped profile wire which is spirally wound around a cage of longitudinal support rods.

Each intersecting point of these wires is fusion welded.

The pitch of winding gives different spacing between two adjacent turns of wire.

This spacing gives passage for water to enter.

The entire process is completed on fully computerized machines.

Wire wraped screen, also be named Wire wrapped screen pipe, Johnson Screen, Spiral screen tube, Welded wedge wire screen, Continuous slot pre-pack, Water filter, Screen cylinders, Stainless steel slot tube,Strainer pipe, Continuous slot wire wrap well screens, Pipe base well screen

Specification:

Regular Specifications:

Material: stainless steel 302, 304, 316, 304L, 316L or low carbon galvanized
O.D.: 2, 3, 4, 6, 8, 10, 12 inch and as request.
Slot: 0.1mm - 35mm
Discrepancy: + / - 0.05mm
Length: 50mm-6000mm
End Connection: welded rings or thread couplings ( male / female )
Specification of the wrap wire:2*3.5mm, 2.2*3.5mm, 3*4.6mm ,3*5mm, 3*6mm,3*7mm.
Specification of the rod:2.8mm, 3.0mm, 3.8mm, 4.0mm, 4.2mm, 4.5mm, 5.0mm and so on.

Special specification can be made according to your requirement !

Advantages:

Non-clogging capabilities

Self supporting

High abreaction resistance

Large open area

Better sand filtration

Energy saving

Lowest possible cost

Long using life

Maximum flow capacity


Application of First choice of industrial Wire Wrap Screen

1. Water well smining & Mineral Processing

2. Municipal water supply, refining & petrochemical

3. Water treatment

4. Architecture and construction, etc.
