Rust Proof Water Well Screen Pipe For Reducing Well Entry Surface Erosion
Rust Proof Water Well Screen Pipe For Reducing Well Entry Surface Erosion
Rust Proof Water Well Screen Pipe For Reducing Well Entry Surface Erosion
Rust Proof Water Well Screen Pipe For Reducing Well Entry Surface Erosion
Specifications
Brand Name :
Heng Yuan
Model Number :
219mm
Certification :
ISO9000
Place of Origin :
Hebei,China
MOQ :
1pcs
Price :
Negotiation
Payment Terms :
L/C, L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000pcs/Month
Delivery Time :
15-30 Days, Due to the Quantity
Packaging Details :
Moister-Barrier with each piece,800 pcs per 20 ft container
Material :
Stainless Steel
Grade :
SS 304, SS304l, SS316L etc
Slot size :
0.25mm, 0.5mm, 0.63mm, 0.75mm, 1.0 mm, 1.5mm
Diameter :
3 ", 4", 6", 8", 10", 12", 14", 16"
Length :
2900 mm Or 5800mm to fit container
End connection :
Welded rings Or Male/ female threaded
Package :
Woden box,Or Container
Description

304 Water Well Screen Pipe , Water Wire Screen Substitute For Johnson Wound Screen Convenient Operation

Stainless Steel 304 Water Well Screen Pipe Description:

Product Name Stainless Steel 304 Water Well Screen, Johnson Wound Screen
Material Stainless Steel
Grade 304, 304L, 316L,321 etc.
O.D 114mm, 168mm, 219mm, 273 mm,325mm, 356mm, 426mm
Size 4" , 6", 8", 10 ", 12", 14", 16"
Slot size 0.5mm, 0.63mm, 0.75mm, 1.0 mm, 1.5mm
Length 2.9m or 5.8 m to fit container
End connection Thread Couplings ( male / female ) OR Welded Rings
Wire size 118 # etc.
Support rod 140 # etc. Round Wire
Wire shape Vee shaped Wire

Stainless Steel 304 Water Well Screen Pipe Parameter selection table:

Special specification can be made according to your need!

SIZE

(INCH)

O.D

(MM)

SLOT

(MM)

LENGTH

(M)

COLLAPSE

STRENGTH

(BAR)

TENSILE

WEIGHT

(TON)

WRAP WIRE(WIDTH*HEIGHT)

(MM)

RODS

(MM)
3-1/2 88.9 1.0 3 ＞22 10.2 2.3*3.5 3.8MM/22
4-1/2 114.3 1.0 3 ＞28 11.5 2.3*3.5 3.8MM/22
6-5/8 168.3 0.75 5.8 ＞40 12.8 2.3*3.5 3.8MM/32
6-5/8 168.3 1.0 5.8 ＞33 12.8 2.3*3.5 3.8MM/32
6-5/8 168.3 0.63 5.8 ＞83 45 3.2*6.0 6.0MM*32
8-5/8 219.1 1.0 5.8 ＞34 21.9 2.3*3.5 3.8MM/48
8-5/8 219.1 1.0 5.8 ＞50 38.2 3.0*5.0 4.0MM/48
8-5/8 219.1 1.0 5.8 ＞60 46 3.2*6.0 5.0MM/48
10-3/4 273.1 0.75 5.8 ＞50 32.9 2.3*3.5 4.9MM/55
10-3/4 273.1 1.0 5.8 ＞60 39.5 3.0*5.0 4.9MM/55
10-3/4 273.1 1.0 5.8 ＞100 48 3.2*6.0 5.0MM/55
12-3/4 323.9 1.0 5.8 ＞120 37.2 3.0*5.0 4.0MM/50
14 355.6 1.0 3 ＞80 37.8 3.0*5.0 4.0MM/59

Stainless Steel 304 Water Well Screen Pipe Advantages:

When compared to conventional slotted pipe, Water Well Screens have superior open area due to their continuous slot openings.

The benefits of which will :


• Reduce energy consumption and increase water flow.
• Reduce erosion of entry surfaces and increase well life.
• Allow a uniform and efficient well development.
• Reduce significantly potential pump damage and subsequent maintenance costs.
