Technical parameters
| Cabin | Driving type 6*4 LHD/RHD Model ZZ HW76, 1bed, AC | |
| Special device | Chinese brand double pump, with HYVA hrdaulic system Tank material: carbon steel, 5mm | |
| Overall Size(mm) | 9760*2500*3500 | |
| Tank capacity(mm) | 15,000liters | |
| Wheel base(mm) | 4600+1350 | |
| GVW(kg) | 25000 | |
| Front axle loading capacity(kg) | 1*7000 | |
| Rear axle loading capacity(kg) | 2*16000 | |
| Engine | Brand | Sinotruk |
| Model | WD615.47 | |
| Type | 4-stroke direct injection, 6-cylinder in-line with water cooling, turbo-charging and inter-cooling | |
| Displacement | 9.726L | |
| Bore*Stroke | 126*130mm | |
| Hose Power(HP) | 336HP | |
| Emission standard | Euro 2 | |
| Max speed | 82km/h | |
| Tire | 12.0-20, 12.00R20, 295/80R22.5, 12R22.5, 315/80R22.5 optional | |
| Transmission | HW19710 transmission, 10 forward and 2 reverse | |
| Steering | ZF81188 | |
| Fuel tank | 400L Aluminum alloy fuel tank | |
| Brake system | Service brake: dual circuit compressed air brake Parking brake (emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust valve brake | |
|
Electrics | Operating voltage:24V,negative grounded Batteries:2x12 V,165 Ah horn,headlamps,fog lights,brake lights,indicators and reverse light | |
| Options | Vertical Muffler; ABS; Automatic Break Clearance Adjusting Arm; Traveling Data; ZF Gearbox PTO ADR | |
