Specifications
Brand Name :
SINOTRUCK
Model Number :
JNHTC
Certification :
ISO CCC
Place of Origin :
JINAN
MOQ :
1 units
Price :
usd 30880~33880
Supply Ability :
50 per week
Delivery Time :
45~50 working days
Packaging Details :
nude
Transmission typeTransmission type :
manual
fuel :
diesel
GVW :
70000kg
seats :
2
displacement :
9.726L
tire :
radial
Volume :
30cubic
Carriage turning mode :
front lifting style
brand :
sinotruck
Place of origin :
shandong
Description

Top Quality Sinotruck Howo 6*4 Underground Mine Truck 30cubic Mine Truck 50tons Mining Truck For Sale

Sinotruck Mining Dump Truck Tipper 10 Wheels 50ton Coal To DR Congo

Sinotruck Mining Dump Truck Tipper 10 Wheels 50ton Coal To DR Congo

Sinotruck Mining Dump Truck Tipper 10 Wheels 50ton Coal To DR CongoSinotruck Mining Dump Truck Tipper 10 Wheels 50ton Coal To DR CongoSinotruck Mining Dump Truck Tipper 10 Wheels 50ton Coal To DR Congo

GVW
75000kg
Driving Type 6x4
Model
ZZ5707V4040CJ
Cargo Body Dimension(mm)
6200*3100*1800
Thickness of Cargo Body
Bottom:14mm, side:12mm
Front Axle
HF12,12 tons front axles of equipped with drum brakes
Rear Axles
AC26,heavy reduction drive axle,STR hub-reduction with differential locks between wheels and axles, enforced STR axle.
Steering
ZF8118,hydraulic steering with power assistance
TranTransmission
HW21712, 12 forward and 2 reverse
Clutch
430 diaphragm spring clutch Type A, hydraulic air booster
Tyres
14.00-25,big size mining use special tire,10+1spare tire
Hydraulic Lift System
Front Lift
Model
D12.42
Engine
Horsepower
420
Maximum output Kw/r/min
309/2000
Maximum torque N.m/r/min
1820/1100-1500
Type
6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection
Bore x Stroke
126x155mm
Valve
4
Displacement
11.596L
Cab
SINOTRUK HW7D single side cab,no bunk,left driving,air conditioner
