Specifications
Brand Name :
Changshu
Model Number :
7628
Certification :
ISO9001:2008
Place of Origin :
China
MOQ :
500 Meters
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, wESTERN uNION
Supply Ability :
10000 Square Meters per day
Delivery Time :
14 Days after the Payment
Packaging Details :
Carton Box，Woven Bag
Product Name :
100% Fiberglass 7628 Lightweight Plain Woven Fiberglass Cloth For Electronic Insulation Materials
Material :
100% E-glass Fiberglass Yarn
Weave type :
Plain Woven
Alkali content :
Alkali Free
Weight :
180g/m2
Application :
PTFE Coated Glass Cloth
Keyword :
Heat Resistant Fabric
Roll length :
50 - 300 m
Features :
Fireproof
Description

100% Fiberglass 7628 Lightweight Plain Woven Fiberglass Cloth For Electronic Insulation Materials

1. Descriptions:

Jiangnan electronical fiberglass fabric is made by high quality E glass fiber filament yarn. 7628 glass is woven by EC9 68x1 Z28 starch fiberglass yarn, 9um fiber diameter formed through 800 holes bushing. E-Glass Filament Loomstates are made of continuous fiberglass yarns, therefore it can be produced in many different kinds of weaving structure, and the surface of this fabrics appear very smooth and shiny. This kind of fabrics have the same properties of Texturized fiberglass fabrics, it is a ideal fabric for all kinds of finish treatments

During wrapper, the fiberglass yarn was further finished in the slasher with material protecting the yarn from mechanical friction. This process can make sure the final glass cloth minimum flaws, very neat, smoothly that can be uniformly composite with copper sheet.

2. Specifications:

7628 Fiberglass Fabric Technique Data sheets
Type Electrical Fiberglass Fabric
Weight 180g/m2
Width 1.27m or Customized
Roll Length 50m, 100m, 150m, 200m
Temperature Resistance -70°C to 550°C
Kniting Type Plain
Glass Yarn Type E-glass or C-glass
Warp/Weft Yarn Type G75/G75
Weave Plain Weave

4. Product Application

PTFE coated glass cloth and other coating material.
Copper clad lamination
Insulation board
Fire prevention cloth
Reinforce plastics and composites
Aircraft, automobiles
Boat, surfboard building
Bath tubs and enclosures, hot tubs building
Water tanks, swimming pools
5. Product Features
Neat fabric surface, even thickness
Good resin wet out and easily heat clean
Good for further process, coating and lamination
Available silane, starch sizing
6. More Pictures for Product and Package
100% Fiberglass 7628 lightweight Plain woven fiberglass cloth for electronic Insulation materials
100% Fiberglass 7628 lightweight Plain woven fiberglass cloth for electronic Insulation materials

7. Related Products (If you want to other different thickness for fiberglass fabric)

Fiberglass Cloth Roving
Item Name Thickness (mm) Weight (g/m2) Weave Width Length (cm) Remarks
E7628 0.18 180 Plain 127 All Size Can be Customized
C7628 0.2 200 Plain 100/130/150
CW280 0.28 280 Plain 102
E3732 0.38 430 1/3 Satin 100/120/150/180/200
C3732 0.38 430 1/3 Twill 100/120/150/180/200
2523 0.38 380 Plain 100/120/150/180/200
E666 0.6 630 8H Satin 100/120/150/180/200
C666 0.6 630 8H Satin 100/120/150/180/200
E3784 0.8 850 8H Satin 100/120/150/180/200
C3784 0.8 850 8H Satin 100/120/150/180/200
E3786 1.2 850 8H Satin 100/120/150/180/200
C3786a 1.2 1000 12H Satin 100/120/150/180/200
C3786b 1.2 1200 12H Satin 100/120/150/180/200
C3786c 1.2 1300 12H Satin 100/120/150/180/200
E3788 1.6 1650 12H Satin 100/120/150/180/200
C3788 1.6 1650 12H Satin 100/120/150/180/200
