60mm Square Integrated DC Servo Motor 200/400W RS485 Control
60mm Square Integrated DC Servo Motor 200/400W RS485 Control
60mm Square Integrated DC Servo Motor 200/400W RS485 Control
60mm Square Integrated DC Servo Motor 200/400W RS485 Control
60mm Square Integrated DC Servo Motor 200/400W RS485 Control
60mm Square Integrated DC Servo Motor 200/400W RS485 Control
60mm Square Integrated DC Servo Motor 200/400W RS485 Control
60mm Square Integrated DC Servo Motor 200/400W RS485 Control
Specifications
Brand Name :
Jkongmotor
Model Number :
JKIDS60-P02A
Certification :
CE, ROHS,ISO9001
Place of Origin :
Jiangsu, China (Mainland)
MOQ :
3-10pcs
Price :
USD75.00
Payment Terms :
T/T , paypal , Western Union, L/C
Supply Ability :
100000pcs/month
Delivery Time :
For samples , 7-15 days / For batch , 15-25days
Packaging Details :
with export carton . big quantity with pallet
Name :
BL DC motor
Current :
11.5A
Rated Torque :
1.27N.m
Rated Speed :
3000±10%rpm
Rated Power :
400w
Phase Inductance :
0.49±20%
Phase Resistance :
0.25±10%
Description

1.Genaral Specification of 60mm Square Integrated DC Servo Motor 200/400W RS485 Control :

  • Model: JKIDS60-P02A
  • Power: 400W
  • Rated Voltage:48V
  • Rated Current: 11A
  • Rated Speed:3000rpm
  • Rated Torque: 1.27N.m
  • Total Height: 112mm

2.Electrical Specification of 60mm Square Integrated DC Servo Motor 200/400W RS485 Control:

Model No.

Power

Rated Voltage

Rated Current

Rated Speed

Rated Torque

Total Height

Encoder

Control method
( w) (VDC) (A) (rpm) (N.m) (L)mm (optional)
JKIDS60-P01A 200 24 11.5 3000 0.63 94 17bit pulse RS485 CANopen
JKIDS60-P02A 400 48 11.5 3000 1.27 112 17bit pulse RS485 CANopen

3.Drawing of 60mm Square Integrated DC Servo Motor 200/400W RS485 Control:

60mm Square Integrated DC Servo Motor 200/400W RS485 Control

4.Produce equipment:

60mm Square Integrated DC Servo Motor 200/400W RS485 Control

5.Production Process:
60mm Square Integrated DC Servo Motor 200/400W RS485 Control

6.Advantages of 60mm Square Integrated DC Servo Motor 200/400W RS485 Control:

  • Adopting a new 32-bit M4+core with120M or 240M main frequency
  • Stable torque characteristics from low to high speeds,with high speed and precision
  • Equipped with brake resistor interface to prevent damage to the electromechanical braking system
  • Wide speed range,low temperature rise and high efficiency
  • Integrated motor and drive ,compact size,simple wiring,and drive
  • Good compatibility with the motor
  • Equipped with overcurrent,overvoltage,over temperature,and over differential protection functions
  • Configure a 17 bit single turn absolute encoder

60mm Square Integrated DC Servo Motor 200/400W RS485 Control60mm Square Integrated DC Servo Motor 200/400W RS485 Control60mm Square Integrated DC Servo Motor 200/400W RS485 Control60mm Square Integrated DC Servo Motor 200/400W RS485 Control
