ISO9001 High Torque 110mm 2KW Brushless Dc Motor 3000 RPM Speed
ISO9001 High Torque 110mm 2KW Brushless Dc Motor 3000 RPM Speed
ISO9001 High Torque 110mm 2KW Brushless Dc Motor 3000 RPM Speed
ISO9001 High Torque 110mm 2KW Brushless Dc Motor 3000 RPM Speed
ISO9001 High Torque 110mm 2KW Brushless Dc Motor 3000 RPM Speed
ISO9001 High Torque 110mm 2KW Brushless Dc Motor 3000 RPM Speed
ISO9001 High Torque 110mm 2KW Brushless Dc Motor 3000 RPM Speed
ISO9001 High Torque 110mm 2KW Brushless Dc Motor 3000 RPM Speed
ISO9001 High Torque 110mm 2KW Brushless Dc Motor 3000 RPM Speed
ISO9001 High Torque 110mm 2KW Brushless Dc Motor 3000 RPM Speed
ISO9001 High Torque 110mm 2KW Brushless Dc Motor 3000 RPM Speed
ISO9001 High Torque 110mm 2KW Brushless Dc Motor 3000 RPM Speed
Specifications
Brand Name :
Jkongmotor
Model Number :
JK110BLS125
Certification :
CE, ROHS, ISO
Place of Origin :
Jiangsu, China (Mainland)
MOQ :
3-10pcs
Price :
US $80 - 120 / Pieces | 1 Piece/Pieces (Min. Order)
Payment Terms :
T/T , paypal , Western Union, L/C
Supply Ability :
30000PCS/MONTH
Delivery Time :
For samples , 7-15 days / For batch , 15-25days
Packaging Details :
with export carton . big quantity with pallet
Product name :
110mm BLDC motor
Speed :
3000rpm
Rated Current :
7.7A
Output Power :
2070W
Voltage :
310V
Body length :
205mm
holding torque :
6.6N.m
Number of poles :
8
shaft diameter :
19mm
Back E.M.F Constant :
91.1V/Krpm
phase :
3
application :
Industrial
Insulation class :
Class F
MOQ :
10pcs
Description

Jkong motor 110bls high torque big power brushless dc motor 1000 watt 2000 watt dc motor

Product Description:

110mm brushless dc motor , BLDC MOTOR

310v dc brushless motor, 110mm dc brushless motor,

3000RPM DC brushless motor

Specification of 3000RPM high speed DC motor:

Model
Specification Unit JK110BLS125
Number Of Phase Phase 3
Number Of Poles Poles 8
Rated Voltage VDC 310
Rated Speed Rpm 3000
Rated Torque N.m 6.6
Rated Current Amps 7.7
Rated Power W 2070

ISO9001 High Torque 110mm 2KW Brushless Dc Motor 3000 RPM Speed

Are brushless DC motors better?

Brushless Motor Advantages

Since brushless DC motors have no brushes to get worn out, they represent a huge leap forward in technology. Brushless motors have significantly higher efficiency and performance, and a lower susceptibility to mechanical wear than their brushed counterparts.

Can you have a brushless DC motor?

Brushless DC motors offer long life and ease of maintenance

DC motors can be further divided into brushed DC motors and brushless DC motors, depending on whether they have brushes (electrodes). These motors work by means of the mechanical linkage between their commutator and brushes.
