Square High Torque Stepper Motor With Brake Nema 23 2N.M 24V 3A 1.8°Step Angle
Square High Torque Stepper Motor With Brake Nema 23 2N.M 24V 3A 1.8°Step Angle
Square High Torque Stepper Motor With Brake Nema 23 2N.M 24V 3A 1.8°Step Angle
Square High Torque Stepper Motor With Brake Nema 23 2N.M 24V 3A 1.8°Step Angle
Specifications
Brand Name :
Jkongmotor
Model Number :
JK57HS112-3004
Certification :
CE, ROHS,ISO9001
Place of Origin :
Jiangsu, China (Mainland)
MOQ :
3-10pcs
Price :
US$23.5~US$37
Payment Terms :
T/T , paypal , Western Union, L/C
Supply Ability :
100000pcs/month
Delivery Time :
For samples , 7-15 days / For batch , 15-25days
Packaging Details :
with export carton . big quantity with pallet
Nema :
hybrid stepper motor
Leads :
4
Current :
3A
Holding Torque :
3.0 N.m
Leading Wires :
4
Driver :
JKD5056S
Shaft :
Single
Application :
computer printers, plotters,image scanners,CNC machines
Description

30kg.cm High Torque Hybrid Square Stepper Motor Nema23 With Brake pad 2N.m 24V 1.8° Step Angle

Genaral Specification:

Item Specifications
Step Angle 1.8°
Temperature Rise 80℃max
Ambient Temperature -20℃~+50℃
Insulation Resistance 100 MΩ Min. ,500VDC
Dielectric Strength 500VAC for 1minute
Shaft Radial Play 0.02Max. (450g-load)
Shaft Axial Play 0.08Max. (450g-load)
Max. radial force 75N (20mm from the flange)
Max. axial force 15N


Electrical Specification:

Model No. Step Angle Motor Length

Current

/Phase

Resistance

/Phase

Inductance

/Phase

 Holding Torque # of Leads Detent Torque Rotor Inertia Mass
( °) (L1)mm A Ω mH N.m No. g.cm g.cm Kg
JK57HS100-4204 1.8 100 4.2 0.75 3 3 4 1100 700 1.3
JK57HS112-3004 1.8 112 3 1.6 7.5 3 4 1200 800 1.4


Brake Specification:

Model BK2
Torque(N-m) 2
Voltage(V) 24V
L2 Length(mm) 32

Square High Torque Stepper Motor With Brake Nema 23 2N.M 24V 3A 1.8°Step AngleSquare High Torque Stepper Motor With Brake Nema 23 2N.M 24V 3A 1.8°Step Angle

Stepper Motor Advantages

  • Low cost for control achieved
  • High torque at startup and low speeds
  • Ruggedness
  • Simplicity of construction
  • Can operate in an open loop control system
  • Low maintenance
  • Less likely to stall or slip
  • Will work in any environment
  • Can be used in robotics in a wide scale.
  • High reliability
  • The rotation angle of the motor is proportional to the input pulse.
  • The motor has full torque at standstill (if the windings are energized)
  • Precise positioning and repeatability of movement since good stepper motors have an accuracy of 3–5% of a step and this error is non-cumulative from one step to the next.
  • Excellent response to starting/stopping/reversing.
  • Very reliable since there are no contact brushes in the motor. Therefore, the life of the motor is simply dependent on the life of the bearing.
  • The motors response to digital input pulses provides open-loop control, making the motor simpler and less costly to control.
  • It is possible to achieve very low-speed synchronous rotation with a load that is directly coupled to the shaft.
  • A wide range of rotational speeds can be realized as the speed is proportional to the frequency of the input pulses.

Stepper Motor Applications

  • As the stepper motor are digitally controlled using an input pulse, they are suitable for use with computer controlled systems.
  • They are used in numeric control of machine tools.
  • Used in tape drives, floppy disc drives, printers and electric watches.
  • The stepper motor also use in X-Y plotter and robotics.
  • It has wide application in textile industries and integrated circuit fabrications.
  • The other applications of the Stepper Motor are in spacecrafts launched for scientific explorations of the planets etc.
  • These motors also find a variety of commercial, medical and military applications and also used in the production of science fiction movies.
  • Stepper motors of microwatts are used in the wrist watches.
  • In the machine tool, the stepper motors with ratings of several tens of kilowatts is used.
