Green Diameter 3mm - 20mm Smooth Polyurethane Round Belt 85a Hardness
Green Diameter 3mm - 20mm Smooth Polyurethane Round Belt 85a Hardness
Green Diameter 3mm - 20mm Smooth Polyurethane Round Belt 85a Hardness
Green Diameter 3mm - 20mm Smooth Polyurethane Round Belt 85a Hardness
Green Diameter 3mm - 20mm Smooth Polyurethane Round Belt 85a Hardness
Green Diameter 3mm - 20mm Smooth Polyurethane Round Belt 85a Hardness
Green Diameter 3mm - 20mm Smooth Polyurethane Round Belt 85a Hardness
Green Diameter 3mm - 20mm Smooth Polyurethane Round Belt 85a Hardness
Specifications
Brand Name :
jiuna
Model Number :
Diameter 2mm-20mm
Certification :
ROHS
Place of Origin :
china
MOQ :
10 rolls
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
100.000 meters per Month
Delivery Time :
Within 5 working days After receipt of your deposit
Packaging Details :
Inner packing is plastic film .outer packing is carton
hardness :
85A
color :
green
heat-resistant :
-30℃~80℃
Type :
PU round belt
material :
PU
Surface :
rough
Description

Green Diameter 3mm - 20mm Smooth Polyurethane Round Belt 85a Hardness
PU Round Belt(smooth/rough)
(1) Thermoplastic polyurethane material, easy to be melted jointed,100% pure polyurethane
(2) Reinforced by Polyester Cord or Steel Cord
(3) Temperature range -35 degree - 80 degree
(4) Shore A hardness range 80A - 98A
(5) With excellent resistance to flex, abrasion resistance, easy jointed and other characteristics. Widely used in textile, packaging, printing, machinery, electronic, glass, chemicals, ceramics and other industries, especially in the ceramic industry, widely used in the facilities line the glaze, polishing lines, and transmission line.
(6) Dia. is from 2mm to 30mm. Smooth Belt with good surface finish; Rough belt with even surface roughness. They are used widely.
Products introduction:
Urethane round belts are elastomeric belts for power transmission application.
Having most metric sizes (2mm to 20mm) and standard O-ring sizes.
Polyether and Polyurethane round belts have best resilience of any elastic material.
Polyester product has good wear resistance, its wear resistance is 3.5 times of common plastic and rubber.
Service commitment:

Items NO.Φ

Least radius of gyration

Stretching rate

Maximum tensile rate

Hardness

Length of rolled

DIA(mm)

In

mm

%

Kg

Lbs

Shore( A)

Length of rolled

2mm

0.79

20

1.5-3%

0.3

0.7

95

400

2.5mm

0.87

22

1.5-3%

0.4

0.9

95

400

3mm

0.98

25

1.5-3%

0.7

1.6

90

400

3.5mm

1.18

30

1.5-3%

0.95

2.1

90

400

4mm

1.38

35

1.5-3%

1.2

2.7

90

200

5mm

1.57

40

1.5-3%

2.0

4.3

90

100

6mm

1.97

50

1.5-3%

3.2

7.0

90

100

7mm

2.17

55

1.5-3%

4.1

9.0

90

100

8mm

2.56

65

1.5-3%

5.0

11.0

90

100

9mm

2.95

75

1.5-3%

6.8

15.0

90

50

10mm

2.95

75

1.5-3%

7.7

17.0

90

50

12mm

3.94

100

1.5-3%

12.2

27.0

90

30

15mm

4.72

120

1.5-3%

17.7

39.0

90

30

18mm

5.71

145

1.5-3%

25.4

56.0

90

30

20mm

6.30

160

1.5-3%

31.3

69.0

90

30


“ Quality for keeping going ,Credit to win the world”
