Specifications
Brand Name :
ACDP-2 Module22 with License A400
Model Number :
Yanhua ACDP-2 Module22 with License A400
Place of Origin :
CHINA
MOQ :
1
Price :
199$
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1000
Delivery Time :
1 work day
Packaging Details :
18*9*4.5cm / 0.1KG
Model Name :
Yanhua Module22 with License A400
Origin :
Mainland China
Quality :
Superior
Item Type :
Auto Key Programmer
Car Maker :
For many models
Hardware Version :
Yanhua ACDP-2 Module22 with License A400
Communication interface :
USB, WIFI
Function 1 :
EEPROM Programming ( work with specific module, buy extra)
Function 2 :
For BMW module Programming ( buy extra Module )
Function 3 :
For JLR module Programming ( buy extra Module )
Function 4 :
For Por-sche BCM module Programming ( buy extra Module )
Function 5 :
For V-W MQB module Programming ( buy extra Module )
Function 6 :
For Fujitsu CPU module Programming ( buy extra Module )
Function 7 :
Clear EGS ISN ( work with specific module , buy extra)
Function 8 :
For Volvo ECM Key Programming ( buy extra Module )
Function 9 :
For V-W/Au-di Gearbox Clone Module ( buy extra Module )
Function 10 :
More modules are in developing ( buy extra Module )
Description

Product Description

  1. Yanhua ACDP Module22 Supports GM 6L45, 6L50, 6L80, 6L90 gearbox clone
  2. Supports GM 6T30, 6T35, 6T40, 6T45, 6T50, 6T70, 6T75, 6T80 gearbox clone
  3. Without soldering, no risk and fast

Yanhua Mini ACDP ACDP-2 Module22 with License A400 for GM6T/6L Gearbox Clone GM TCU Transsion Clone No Need Soldering

#22_ GM 6T/6L Gearbox Clone with License A400
Support 6T30/6T35/6T40/6T45/6T50/6T70/6T75/6T80/6L45/6L50/6L80/6L90 gearbox clone.

Suppported Model:

1. Support GM 6T30/6T35/6T40/6T45/6T50 gearbox clone
2. Support GM 6T70/6T75/6T80 gearbox clone
3. Support GM 6L45/6L50/6L80/6L90 gearbox clone

Features:

1. Using special interface board to replace the wiring, to avoid wrong connection
2. Simple and efficient, plug and play, safe and reliable

Functions:

1. Identify
2. Full Backup Data
3. Full Write Data
4. Read/Write INT FLASH
5. Read/Write INT EEPROM
6. Special functions: Modify VIN, Modify programming date, modify final part number, Modify broadcast code B5

APP Operation Interface:

Yanhua Mini ACDP ACDP-2 Module22 with License A400 for GM6T/6L Gearbox Clone GM TCU Transsion Clone No Need Soldering

Yanhua Mini ACDP ACDP-2 Module22 with License A400 for GM6T/6L Gearbox Clone GM TCU Transsion Clone No Need Soldering

Overall Connection Diagram:

Yanhua Mini ACDP ACDP-2 Module22 with License A400 for GM6T/6L Gearbox Clone GM TCU Transsion Clone No Need Soldering
Yanhua Mini ACDP ACDP-2 Module22 with License A400 for GM6T/6L Gearbox Clone GM TCU Transsion Clone No Need Soldering

Yanhua Mini ACDP ACDP-2 Module22 with License A400 for GM6T/6L Gearbox Clone GM TCU Transsion Clone No Need Soldering


How to Clone GM 6T/6L Gearbox with Yanhua ACDP and Module 22?

Run ACDP mini app, select GM- Gearbox Clone
Select specific gearbox type. If you don't know the wiring diagram,Please click "Help" to check.
Note: Please Ensure the backup(old) gearbox model is same as the donor's,otherwise it may cause risk of death by different hardware structures.
After set up connection, full backup data before operation. Read and save original data and then Write to new gearbox module.

6T30, 6T35, 6T40, 6T45 and 6T50 use the GT-6TXX-X1 interface board:

Yanhua Mini ACDP ACDP-2 Module22 with License A400 for GM6T/6L Gearbox Clone GM TCU Transsion Clone No Need Soldering
Yanhua Mini ACDP ACDP-2 Module22 with License A400 for GM6T/6L Gearbox Clone GM TCU Transsion Clone No Need Soldering

6T70/6T75/6T80 Use 6TXX-X2 interface board:

Yanhua Mini ACDP ACDP-2 Module22 with License A400 for GM6T/6L Gearbox Clone GM TCU Transsion Clone No Need Soldering
Yanhua Mini ACDP ACDP-2 Module22 with License A400 for GM6T/6L Gearbox Clone GM TCU Transsion Clone No Need Soldering

6L45/6L50/6L80/6L90 Use the GM 6LXX interface board:

Yanhua Mini ACDP ACDP-2 Module22 with License A400 for GM6T/6L Gearbox Clone GM TCU Transsion Clone No Need Soldering
Yanhua Mini ACDP ACDP-2 Module22 with License A400 for GM6T/6L Gearbox Clone GM TCU Transsion Clone No Need Soldering

Yanhua ACDP Module 22 Package List:

Yanhua Mini ACDP ACDP-2 Module22 with License A400 for GM6T/6L Gearbox Clone GM TCU Transsion Clone No Need Soldering
