Specifications
Brand Name :
JIMA
Model Number :
JIMAFOR
Certification :
IATF 16949 NADCAP CE
Place of Origin :
CHINA
MOQ :
1PCS
Price :
Negotiations
Payment Terms :
T/T, L/C
Supply Ability :
7000PCS /per month
Delivery Time :
7~30days
Packaging Details :
wooden pallet
Item :
45 steel, 40Cr Traction motor shaft,Precision Splined Traction Shaft for E-Axle,EV Traction Shaft Manufacturer
Technology :
Forging/rolling → rough machining
Sample :
Supply ,Can customized
Material :
18CrNiMo7-6 42CrMoH Medium carbon alloy structural steel 45 steel, 40Cr)
Description

45 steel, 40Cr Traction motor shaft,Precision Splined Traction Shaft for E-Axle,ISO 1940 G2.5 Balanced,Custom OEM

JIMAFor offer solutions for perfect machining of EV Traction Shaft Manufacturer

OUR Products includs :

Drive Shaft
E-Axle Shaft
EV Motor Shaft
Heavy Duty Traction Shaft
Precision Ground Motor Shaf
Splined Traction Shaft
Water-Cooled Traction Shaft Supplier
Custom Length E-Axle Shaft Manufacturer
Mining Truck Drive Shaft USA

EV Traction Shaft Manufacturer

Process feasibility:

Forging/rolling → rough machining → quenching and tempering (180-220HB) → fine grinding (journal roughness Ra0.8μm or less) → dynamic balancing test

Fine machining ensures dimensional accuracy, dynamic balancing controls vibration (≤2.5g・mm/kg)

Key process highlights:

Wedge transverse rolling near-net forming: hot rolling at 1140-1160°C, 1-2mm margin reserved, flow lines distributed along the tooth shape, fatigue strength ↑25%5.
Cold rolling and extrusion spline: shaping the tooth shape in a single reciprocating motion, avoiding concentration of cutting stresses, tooth root fatigue limit ↑40%5.
Turning instead of grinding: precision turning of quenched parts (Ra ≤ 0.8μm), alternative to grinding, efficiency ↑18% and environmentally-friendly


Application
High-speed train
New energy mining truck
Robotic arm
High-speed rail/city rail
Construction machinery

OUR Core Services
1. personalisation - support customisation, accurately restore your design needs.
2. Sample Service - Provide professional sampling to ensure product quality.
3. Innovation Support - Provide professional design and R & D services to help you realise your creative ideas.
