OIL PUMP ASSEMBLY 12VB.17.00C Jichai G12V190PZL diesel engine used in drilling rig
OIL PUMP ASSEMBLY 12VB.17.00C Jichai G12V190PZL diesel engine used in drilling rig
OIL PUMP ASSEMBLY 12VB.17.00C Jichai G12V190PZL diesel engine used in drilling rig
OIL PUMP ASSEMBLY 12VB.17.00C Jichai G12V190PZL diesel engine used in drilling rig
OIL PUMP ASSEMBLY 12VB.17.00C Jichai G12V190PZL diesel engine used in drilling rig
OIL PUMP ASSEMBLY 12VB.17.00C Jichai G12V190PZL diesel engine used in drilling rig
Specifications
Brand Name :
jichai
Model Number :
G12V190PZL
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
1
Price :
3478
Supply Ability :
234
Packaging Details :
wooden cases
Description

Series 2000 Diesel Engines

Performance Parameters

Model Rated Power (kW/hp) Rated Speed (r/min) Specific Fuel Consumption (g/kW·h) Specific Oil Consumption (g/kW·h) Overall Dimensions (L×W×H mm) Net Weight (kg)
BG12V190ZL 900 / 1500 800 / 1500 ≤209.4 ≤1.6 3160 × 1770 × 2400 5300
BG12V190PZL 900 / 1500 800 / 1500 ≤209.4 ≤1.6 4374 × 1740 × 2400 8100
BG12V190ZL-3 810 / 1300 730 / 1300 ≤209.4 ≤1.6 3160 × 1770 × 2400 5300
BG12V190PZL-3 810 / 1300 730 / 1300 ≤209.4 ≤1.6 4374 × 1740 × 2400 8100
G12V190ZL 900 / 1500 800 / 1500 ≤209.4 ≤1.6 2692 × 1560 × 2070 5300
G12V190PZL 900 / 1500 800 / 1500 ≤209.4 ≤1.6 3860 × 2040 × 2678 8100
G12V190ZL-3 810 / 1300 730 / 1300 ≤209.4 ≤1.6 2692 × 1560 × 2070 5300
G12V190PZL-3 810 / 1300 730 / 1300 ≤209.4 ≤1.6 3860 × 2040 × 2678 8100
G12V190ZL-1 740 / 1200 660 / 1200 ≤209.4 ≤1.6 2692 × 1560 × 2070 5300
G12V190PZL-1 740 / 1200 660 / 1200 ≤209.4 ≤1.6 3860 × 2040 × 2678 8100
G12V190ZL-2 600 / 1000 540 / 1000 ≤209.4 ≤1.6 2692 × 1560 × 2070 5300
G12V190PZL-2 600 / 1000 540 / 1000 ≤209.4 ≤1.6 3860 × 2040 × 2678 8100
G8V190ZL 600 / 1500 540 / 1500 ≤213.5 ≤2.7 1802 × 1560 × 2070 4300
G8V190PZL 600 / 1500 540 / 1500 ≤213.5 ≤2.7 3280 × 2040 × 2678 6750
G8V190ZL-3 510 / 1300 460 / 1300 ≤213.5 ≤2.7 1802 × 1560 × 2070 4300
G8V190PZL-3 510 / 1300 460 / 1300 ≤213.5 ≤2.7 3280 × 2040 × 2678 6750
G8V190ZL-1 470 / 1200 425 / 1200 ≤213.5 ≤2.7 1802 × 1560 × 2070 4300
G8V190PZL-1 470 / 1200 425 / 1200 ≤213.5 ≤2.7 3280 × 2040 × 2678 6750
G8V190ZL-2 390 / 1000 350 / 1000 ≤213.5 ≤2.7 1802 × 1560 × 2070 4300
G8V190PZL-2 390 / 1000 350 / 1000 ≤213.5 ≤2.7 3280 × 2040 × 2678 6750

Main Technical Data

Item Specification
No. & Arrangement of Cylinders 12, 60° V-type
Type Four-stroke, water-cooled, turbocharged & aftercooled, direct injection
Bore 190 mm
Stroke 210 mm
Total Displacement 71.45 L (or 47.6 L depending on variant)
Compression Ratio 14 : 1
Direction of Rotation - Counter-clockwise (models without “R”) - Clockwise (models with “R”) (Facing flywheel)
Starting Method Air motor or electric motor
Lubrication Method Pressure + splash lubrication
