0.5mm PETG Thermoform Plastic Sheets 1mm 2mm 3mm PETG Plastic Roll
0.5mm PETG Thermoform Plastic Sheets 1mm 2mm 3mm PETG Plastic Roll
0.5mm PETG Thermoform Plastic Sheets 1mm 2mm 3mm PETG Plastic Roll
0.5mm PETG Thermoform Plastic Sheets 1mm 2mm 3mm PETG Plastic Roll
0.5mm PETG Thermoform Plastic Sheets 1mm 2mm 3mm PETG Plastic Roll
0.5mm PETG Thermoform Plastic Sheets 1mm 2mm 3mm PETG Plastic Roll
0.5mm PETG Thermoform Plastic Sheets 1mm 2mm 3mm PETG Plastic Roll
0.5mm PETG Thermoform Plastic Sheets 1mm 2mm 3mm PETG Plastic Roll
0.5mm PETG Thermoform Plastic Sheets 1mm 2mm 3mm PETG Plastic Roll
0.5mm PETG Thermoform Plastic Sheets 1mm 2mm 3mm PETG Plastic Roll
Specifications
Place of Origin :
Jiangsu, China
Brand Name :
Jiaou
Supply Ability :
100 Ton/Tons per Day 0.5mm 1mm 2mm 3mm Transparent PETG Plastic Sheet Manufacturers
MOQ :
500 kilograms
Price :
$2.10 - $3.50/kilograms
Model Number :
PETG Sheet
Certification :
FDA, GRS, Reach, RoHS, ISO9001
Material :
PETG
Thickness :
0.15-1.5MM-10MM
Size :
2440mm
Product name :
0.5mm 1mm 2mm 3mm Transparent PETG Plastic Sheet Manufacturers
Other Product Name :
PETG Sheet
Origin :
China
Color :
Transparent
Application :
For Packaging vacuum-formed,sale displays, covers and machinery guards
Feature :
Eco-Friendly
Sample :
Available
Packing :
Pallets
Certificate :
ISO
Port :
Shanghai,Lianyungang,Zhangjiagang
Packaging Details :
Sample: A4 size rigid PETG with PP bag in box Sheet packing: 30kg per bag or as your requirement Pallets packing: 500- 2000kg per wooden pallet Container loading: 20 tons as normal
Description

0.5mm 1mm 2mm 3mm Transparent PETG Plastic Sheet Manufacturers

Product Description

PETG sheet is a thermoplastic sheet made by Polyethylene terephthalate resin.PETG offers the capability to produce complex shapes, precise details, deep draws and compound curves without worrying about durability. PETG is easily formed, die-cut and punched. It also brings increased design freedom and lower fabrication costs. In sheet form, PETG has the impact strength and fabrication ease that acrylic can`t touch, with the durability to significantly reduce packaging and shipping costs.

•Outstanding thermoforming characteristics, particularly in deep draw applications
•Good impact resistance
•Less brittle than acrylic
•Resistant to common cleaners used on point of purchase displays
•Allows for rigid thermoforming cycle times
•FDA compliant grades available
•Impact strength greater than acrylic and approaches polycarbonate
•86% light transparency compared to 87% for polycarbonate and 92% for acrylic
•Die cuts/punches easily
•Low forming temperature
•Printable
•Chemical resistant
•Self-extinguishing

Technical Data Sheet
Item Typical Value Testing Method
Intrinsic Viscosity(dL/g) 0.750+/-0.015 Ubbelodhe viscometer
Specific Gravity(kg/cm³) 1.27 ASTM D792
Moisture Absorption(%) 0.15 ASTM D570
Tensile Strength@Yield 50mm/min( inch/min)(kgf/cm²) 496 ASTM D638
Tensile Strength@Break 50mm/min( inch/min)(kgf/cm²) 281 ASTM D638
Elongation@Yield 50mm/min( 2inch/min)(%) 3.7 ASTM D638
Elongation@Break 50mm/min(2 inch/min)(%) 136 ASTM D638
Flexural Strength 1.27mm/min(2 inch/min)(kgf/cm²) 620 ASTM D790
Flexural Strength 1.27mm/min(3 inch/min)(kgf/cm²) 20800 ASTM D790
Low temperature falling dart impact(g) 791 ASTM D358
Atmospheric temperature falling dart(g) 1701 ASTM D358
Lzod Impact Strength Notched@23 ℃(J/m) 98 ASTM D256
Rockwell Hardness(℃) 106 R-scale
Heat Distortion Temperature 0.45Mpa(66 psi)(℃) 77 ASTM D648

Application For PETG Sheet

PETG is used as a Midrange priced product between Acrylic and Polycarbonate. The clearity of PETG approchies that of Acrylic and Impact Resistance of Polycarbonate. Also is used in Signing, Glazing, POP Displays, etc.

•Signs
•Sign and graphic holders
•Point of purchase displays
•Merchandisers
•Table top displays
•Table tents
•Product displays
•Trays

0.5mm PETG Thermoform Plastic Sheets 1mm 2mm 3mm PETG Plastic Roll0.5mm PETG Thermoform Plastic Sheets 1mm 2mm 3mm PETG Plastic Roll

Packaging & Shipping

Package

0.5mm PETG Thermoform Plastic Sheets 1mm 2mm 3mm PETG Plastic Roll

FAQ

FAQ

Q1. Are you a factory or trade company?

A: We are a professional manufacturer with 15 years' experience. If you have any interest, welcome to visit our factory.

Q2. Do you provide samples? Is it free or extra?

A: Yes, we could offer the sample for free, but charge by freight collection.

Q3. How about the lead time?

A: Normal sample supply it at once. Special samples need 3 days. mass production is generally 5-10 working days after receiving your initial payment.

Q4. Do you have any MOQ limits?

A: Normal Only 500kgs, Special colors about 2000kg.

Q5. What are your terms of payment?

A: 30% T/T in advance, balance before shipment. We accept L/C at Sight.
