Specifications
Place of Origin :
Jiangsu, China
Brand Name :
Jiaou
Model Number :
GAG sheets/rolls
Packaging Details :
Sample: A4 size rigid PETG with PP bag in box Sheet packing: 30kg per bag or as your requirement Pallets packing: 500- 2000kg per wooden pallet Container loading: 20 tons as normal
Supply Ability :
100 Tons Per Day
MOQ :
1000 kilograms
Price :
Negociated
Certification :
FDA, GRS, Reach, RoHS, ISO9001
Payment Terms :
T/T, L/C
Delivery Time :
To Be Negotiated
Product name :
GAG Plastic Sheet Solid Transparent Machine Guards
Material :
GAG
Thickness :
0.18-7mm
Size :
Custom
Processing Service :
Cutting
Surface :
Glossy
Application :
Machine guards
Feature :
Fire-proof
Characteristics :
Customized design
Port :
Shanghai, Ningbo, Lianyungang, Zhangjiagang
Description

GAG Plastic Sheet 3MM Clear Solid Transparent GAG Plastic Machine Guards

Product Description

GAG plastic sheet is a three-layer composite sheet. It is a three-layer composite sheet produced by co-extrusion of the middle layer APET and the upper and lower layers of PETG raw materials in an appropriate ratio.

Advantages:

• Outstanding thermoforming characteristics, particularly in deep draw applications
• Good impact resistance
• Less brittle than acrylic
• Resistant to common cleaners used on point of purchase displays
• Allows for rigid thermoforming cycle times
• FDA compliant grades available
• Impact strength greater than acrylic and approaches polycarbonate
• 86% light transparency compared to 87% for polycarbonate and 92% for acrylic
• Die cuts/punches easily
• Low forming temperature
• Printable
• Chemical resistant
• Self-extinguishing

Technical Data Sheet
Item Typical Value Testing Method
Intrinsic Viscosity(dL/g) 0.750+/-0.015 Ubbelodhe viscometer
Specific Gravity(kg/cm³) 1.27 ASTM D792
Moisture Absorption(%) 0.15 ASTM D570
Tensile Strength@Yield 50mm/min( inch/min)(kgf/cm²) 496 ASTM D638
Tensile Strength@Break 50mm/min( inch/min)(kgf/cm²) 281 ASTM D638
Elongation@Yield 50mm/min( 2inch/min)(%) 3.7 ASTM D638
Elongation@Break 50mm/min(2 inch/min)(%) 136 ASTM D638
Flexural Strength 1.27mm/min(2 inch/min)(kgf/cm²) 620 ASTM D790
Flexural Strength 1.27mm/min(3 inch/min)(kgf/cm²) 20800 ASTM D790
Low temperature falling dart impact(g) 791 ASTM D358
Atmospheric temperature falling dart(g) 1701 ASTM D358
Lzod Impact Strength Notched@23 ℃(J/m) 98 ASTM D256
Rockwell Hardness(℃) 106 R-scale
Heat Distortion Temperature 0.45Mpa(66 psi)(℃) 77 ASTM D648

Application For GAG Sheet

GAG plastic sheet is used as a Midrange priced product between Acrylic and Polycarbonate. The clarity of GAG approaches that of Acrylic and the Impact Resistance of Polycarbonate. Also is used in Signing, Glazing, POP Displays, etc.


• Sign and graphic holders
• Point of purchase displays
• Merchandisers
• Tabletop displays
• Product displays
• Trays

Packaging & Delivery

GAG Plastic Sheet Machine Guards 3MM Clear Solid TransparentGAG Plastic Sheet Machine Guards 3MM Clear Solid Transparent

FAQ

Q1. Are you a factory or trade company?
A: We are a professional manufacturer with 15 years experience if you have interest welcome to visit our factory.
Q2. Do you provide samples? Is it free or extra?
A: Yes, we could offer the sample for free, but charge by freight collection.
Q3. How about the lead time?
A: Normal sample supply it at once. Unique samples need 3 days. mass production is generally 5-10 working days after receiving your initial payment.
Q4. Do you have any MOQ limits?
A: Normal Only 1000kgs, Special colors about 5000kgs.
Q5. What are your terms of payment?
A: 30% T/T in advance, balance before shipment. We accept L/C at Sight.
