Blister PET Sheet Film Electronic Device Insert Packaging Transparent PET Sheet
Blister PET Sheet Film Electronic Device Insert Packaging Transparent PET Sheet
Blister PET Sheet Film Electronic Device Insert Packaging Transparent PET Sheet
Blister PET Sheet Film Electronic Device Insert Packaging Transparent PET Sheet
Blister PET Sheet Film Electronic Device Insert Packaging Transparent PET Sheet
Blister PET Sheet Film Electronic Device Insert Packaging Transparent PET Sheet
Blister PET Sheet Film Electronic Device Insert Packaging Transparent PET Sheet
Blister PET Sheet Film Electronic Device Insert Packaging Transparent PET Sheet
Blister PET Sheet Film Electronic Device Insert Packaging Transparent PET Sheet
Blister PET Sheet Film Electronic Device Insert Packaging Transparent PET Sheet
Specifications
Brand Name :
Jiaou
Model Number :
PET Sheet
Certification :
FDA, GRS, Reach, RoHS, Iso9001
Place of Origin :
Jiangsu, China
MOQ :
1000 kilograms
Price :
Negociated
Payment Terms :
T/T
Supply Ability :
30 Tons Per Day
Delivery Time :
To Be Negotiated
Packaging Details :
Sample: A4 size rigid PET with PP bag in box Sheet packing: 30kg per bag or as your requirement Pallets packing: 500- 2000kg per wooden pallet Container loading: 20 tons as normal
Product name :
PET Sheet Film Insert Packaging
Material :
PET
Thickness :
0.18-2mm
Width :
300-1280mm
Process :
Cutting
Color :
Customized
Application :
Food Packaging
Surface :
Smooth,Glossy
Shape :
Sheet; Roll
Raw material :
100% Virgin Raw Material
Description

PET Sheet Film Clear PET Sheet Roll For Blister

Product Description

PET (polyethylene terephthalate) is a thermoplastic material that is part of the group of polycondensates. PET is available as amorphic and semi-crystalline material. We process semi-crystalline PET, which is characterized by a combination of different properties, which render the material particularly suitable for demanding components in mechanical and plant engineering in addition to other areas of application. (Amorphous PET, known from the production of beverage bottles, is not part of our range.)

The properties of PET include but are not limited to:

  • Excellent dimensional stability
  • Very low water absorption
  • Excellent creep rupture behavior
  • Good sliding properties
  • High resistance to wear
  • High strength and stiffness
  • Good machinability
  • Low thermal expansion coefficient

Technical Data Sheet
General Properties Value Test Method Unit
Density 1.36 ISO 1183 g/cm³
Water Absorption 0.25 ISO 62 %
Flammability HB / HB UL 94 /
Mechanical Properties
Yield Stress 85 ASTM D638 MPa
Elongation @ Break 15 ASTM D638 %
Tensile Modulus of Elasticity 3000 ASTM D638 MPa
Notched Impact Strength (Charpy) 2 DIN EN ISO 179 kJ/m2
Ball Indentation Hardness 170 DIN EN ISO 2039-1 MPa
Shore Hardness 84 DIN EN ISO 868 Scale D
Thermal Properties
Melting Temperature 255 ISO 11357-3 °C
Thermal Conductivity 0.28 DIN 52612-1 W / (M*K)
Thermal Capacity 1.1 DIN 52612 kJ / (kg*K)
Coefficient of Linear Thermal Expansion 60 DIN 53752 10-6K-1
Service Temperature, Long Term -20 up to +115 Average °C
Service Temperature, Short Term (Max.) 180 Average °C
Heat Deflection Temperature 80 ASTM D648 °C
Electrical Properties
Dielectric Constant 3.4 IEC 60250 /
Dielectric Dissipation Factor (50Hz) 0.001 IEC 60250 /
Volume Resistivity 10 18 IEC 60093 Ω*cm
Surface Resistivity 10 16 IEC 60093 Ω
Comparative Tracking Index 600 IEC 60112
Dielectric Strength 20 ASTM D149 kV/mm

Application For PET Sheet

Because of its versatile properties, PET sheet is used in various industries - for instance:

  • Mechanical engineering and plant engineering
  • Food industry
  • Conveyors
  • Wind power
  • Electrical engineering

Blister PET Sheet Film Electronic Device Insert Packaging Transparent PET Sheet

Package & Delivery

Blister PET Sheet Film Electronic Device Insert Packaging Transparent PET SheetBlister PET Sheet Film Electronic Device Insert Packaging Transparent PET Sheet

FAQ

Q1. Are you a factory or trade company?

A: We are a professional manufacturer of 15 years' experience. If you have interest welcome to visit our factory.

Q2. Do you provide samples? Is it free or extra?

A: Yes, we could offer the sample for free, but charge by freight collect.

Q3. How about the lead time?

A: Normal sample supply it at once. Special samples need 3 days. Mass production generally needs 5-10 working days after receiving your initial payment.

Q4. Do you have any MOQ limits?

A: Normal Only 1000kgs, Special colors about 5000kgs.

Q5. What are your terms of payment?

A: 30% T/T in advance, balance before shipment. We accept L/C at Sight.
