Fully Automatic 1000L Blow Molding Machine with Accumulator Head Design 500 kg/h Output and 2200 kN Clamping Force
Fully Automatic 1000L Blow Molding Machine with Accumulator Head Design 500 kg/h Output and 2200 kN Clamping Force
Fully Automatic 1000L Blow Molding Machine with Accumulator Head Design 500 kg/h Output and 2200 kN Clamping Force
Fully Automatic 1000L Blow Molding Machine with Accumulator Head Design 500 kg/h Output and 2200 kN Clamping Force
Fully Automatic 1000L Blow Molding Machine with Accumulator Head Design 500 kg/h Output and 2200 kN Clamping Force
Fully Automatic 1000L Blow Molding Machine with Accumulator Head Design 500 kg/h Output and 2200 kN Clamping Force
Fully Automatic 1000L Blow Molding Machine with Accumulator Head Design 500 kg/h Output and 2200 kN Clamping Force
Fully Automatic 1000L Blow Molding Machine with Accumulator Head Design 500 kg/h Output and 2200 kN Clamping Force
Fully Automatic 1000L Blow Molding Machine with Accumulator Head Design 500 kg/h Output and 2200 kN Clamping Force
Fully Automatic 1000L Blow Molding Machine with Accumulator Head Design 500 kg/h Output and 2200 kN Clamping Force
Fully Automatic 1000L Blow Molding Machine with Accumulator Head Design 500 kg/h Output and 2200 kN Clamping Force
Fully Automatic 1000L Blow Molding Machine with Accumulator Head Design 500 kg/h Output and 2200 kN Clamping Force
Specifications
video outgoing-inspection :
Provided
machinery test report :
Provided
core components :
PLC, Engine, Bearing, Gearbox, Gear
plastic processed :
HDPE, PE, HDPE/PP
Place of Origin :
Jiangsu, China
Brand Name :
DAWSON
voltage :
440V/415V/380V/220V
dimension(l*w*h) :
11*7*7
Clamping Force (kN) :
2200
plc brand :
Mitsubishi
Screw L/D Ratio :
30
screw diameter (mm) :
120
output (kg/h) :
500
automation :
Automatic
No. of Screw Heating Zone :
6
screw heating power(kw) :
88
extruder motor power(kw) :
135
mold platen size(width)(mm) :
1800
mold platen size(height)(mm) :
1800
air pressure(mpa) :
0.7
air comsumption(m³/min) :
2.2
die head heating power(kw) :
75
power (kw) :
360
weight (t) :
65
key selling points :
High Productivity
warranty :
1 Year
Blow Molding Type :
Extrusion Blow Molding Machine
Die head type :
Accumulator type
Suitable IBC tank size :
500-1200L
Layer of IBC tank :
single layer, double layer, triple layer available
Color changing time :
half day
Machine installation time :
one day
Language settings :
Chinese and English operation panel
Labor demand :
1~2 operator
Mold Material :
Aluminum profile
Mould Lifespan :
> 3,000,000 Cycles
MOQ :
1
Price :
HK$988,436.50-1,027,973.96
Description
Highlights at a glance
Well-Maintained Used IBC Blow Molding Machine
In good working condition, tested before shipment. Servo Motor System
Energy-saving, stable operation, reduces production costs. Accumulator Head Design
Ideal for 1000L IBC tank production, ensures uniform wall thickness. Strict Quality Inspection
Factory-tested core components with independent R&D support. Customization Available
Supports different molds for 500L/800L/1000L containers. After-Sales Support
Technical service, spare parts supply, and 1-year warranty optional. Working Video & Detailed Specs
Available upon request for full transparency.
Fully Automatic 1000L Blow Molding Machine with Accumulator Head Design 500 kg/h Output and 2200 kN Clamping Force
Fully Automatic 1000L Blow Molding Machine with Accumulator Head Design 500 kg/h Output and 2200 kN Clamping Force
Fully Automatic 1000L Blow Molding Machine with Accumulator Head Design 500 kg/h Output and 2200 kN Clamping Force
USED IBC TANK BLOW MOLDING MACHINE FOR 1000L CONTAINER PRODUCTION 1.Suitable for 1000L IBC tank manufacturing 2.Equipped with servo motor for stable and energy-efficient operation 3.Factory-designed core components with reliable quality 4.Independent R&D and strict inspection process 5.Customization available for different production needs
Fully Automatic 1000L Blow Molding Machine with Accumulator Head Design 500 kg/h Output and 2200 kN Clamping Force
Fully Automatic 1000L Blow Molding Machine with Accumulator Head Design 500 kg/h Output and 2200 kN Clamping Force
Fully Automatic 1000L Blow Molding Machine with Accumulator Head Design 500 kg/h Output and 2200 kN Clamping Force
Fully Automatic 1000L Blow Molding Machine with Accumulator Head Design 500 kg/h Output and 2200 kN Clamping Force
Fully Automatic 1000L Blow Molding Machine with Accumulator Head Design 500 kg/h Output and 2200 kN Clamping Force
Fully Automatic 1000L Blow Molding Machine with Accumulator Head Design 500 kg/h Output and 2200 kN Clamping Force
Fully Automatic 1000L Blow Molding Machine with Accumulator Head Design 500 kg/h Output and 2200 kN Clamping Force
