Durable JEDEC IC Trays for Clean Production and Wafer Dust Protection
Guard delicate semiconductor wafers during production and handling. Sustain clean working environment and block dust particles effectively. Comply with JEDEC standards for reliable industrial use. Seeking trusted tray solutions for wafer packaging and storage?
Integrate seamlessly with automated assembly lines and packaging plants. Perform consistently in wafer transfer and packaging procedures. Adapt smoothly to diverse semiconductor manufacturing processes.
Facilitate safe storage and factory logistics of wafers. Support custom cavity designs to meet specific production demands. Deliver tailored solutions for unique semiconductor manufacturing requirements.
Key Features/ Benefits
- Strong durable structure
- Effective dust prevention
- Safeguard wafer packaging processes
- Comply with JEDEC standards
- Flexible customization
Specifications
| Brand |
Hiner-pack |
| Model |
HN25011 |
| Material |
MPPO |
| Package Type |
JEDEC |
| Color |
Black |
| Resistance |
1.0×10⁴ - 1.0×10¹¹ Ω |
| Outline Line Size |
322.6×135.9×7.62 mm |
| Cavity Size |
8.5×8.5×0.9 mm |
| Matrix QTY |
20x9=180 PCS |
| Warpage |
MAX 0.76mm |
| Service |
Accept OEM, ODM |
| Custom Pocket Options |
Available |
Applications
Apply to semiconductor wafer packaging, component testing, die sorting and semiconductor manufacturing. Fit cleanroom operations, automated assembly lines and packaging plants. Ensure stable performance in rigorous industrial environments.
Also used in wafer storage, factory logistics, production turnover and sample shipment. Serve semiconductor manufacturers, testing institutions and electronic component suppliers.
Customized Services
Offer comprehensive customization services for JEDEC IC trays. Collaborate closely with customers to analyze unique wafer specifications, production workflows, and environmental requirements. Modify cavity dimensions, grid layouts, material selections, and structural designs to perfectly match diverse wafer types and manufacturing scenarios. Provide end-to-end support from prototype testing to final production, delivering personalized tray solutions that enhance production efficiency, minimize contamination risks, and fully address specialized semiconductor manufacturing needs.
About Us:
Hiner-pack® was founded in 2013. It is a high-tech enterprise that integrates Design, R&D, Manufacturing, Sales of IC packaging and testing, as well as semiconductive wafer fabrication process in automated handling, carrying, and transportation to provide customers with turnkey services.
Why Choose Us:
- Rich experience in JEDEC / IC / waffle pack trays
- In-house mold design capability
- Fast prototype development
- Strict QC process
- Stable supply for global semiconductor customers
