Low Altitude Anti Drone System Scalable Networking Control AC220V
Low Altitude Anti Drone System Scalable Networking Control AC220V
Specifications
Model Number :
JDY-900P
Certification :
Design Patent Certificate,Computer Software Copyright Registration Certificate,Utility Model Patent Certificate,Testing Report of Lightning Protection Products Testing Center of Shanghai Lightning Protection Center, etc.
Place of Origin :
China
MOQ :
1
Price :
＄44670
Payment Terms :
T/T,L/C,D/A,D/P,Western Union,MoneyGram
Supply Ability :
200 per month
Delivery Time :
30 days
Packaging Details :
Flight Case
Product Name :
Jdy-900(P) Anti-Uav Single-Station Defense System
Core Tech :
Passive Detection, Wideband Scanning
Detection Freq :
300MHz~6000MHz; 300MHz~9000MHz (Partial)
Key Detection Bands :
2.4G/5.8g/800MHz/900MHz/1.4G/5.2GHz
Detection Dist :
Jdy-900:1~5km; Jdy-900p:1~8km
Positioning Accuracy :
≤10m (Uav); ≤5m (Operator)
Jamming Bands :
2.4G/5.8g/900MHz/GPS/Bds/Glonass/Galileo
Jamming Dist :
1~3km (Depends on Electromagnetic Environment)
Jamming Method :
4-Sector Directional/Omnidirectional Strike
Transmission Power :
360W; 1500W (Partial Versions)
Power Supply :
AC220V→DC24V; DC27V (Partial)
Weight :
≤20.0kg
Operating Temp :
-35ºC~50ºC (Built-in Radiator)
Protection Level :
IP66; IP65 (Partial)
Alarm Mode :
Audible/Visual Alarm
Description
JDY-900(P) Anti-Drone Single-Station Defense System
Leading Advantages

Compared to similar products, the JDY-900(P) excels in the following aspects:

  • Wider Detection: Covering the 300MHz to 6000MHz frequency band, the JDY-900(P) offers a detection radius of 8 kilometers, far exceeding the 3-5km range of traditional devices.
  • Stronger Interference: With an industry-leading interference range of up to 3 kilometers and a transmit power of 360W, it offers an industry-leading countermeasure range.
  • More Accurate Positioning: Drone positioning accuracy is ≤10 meters, and pilot positioning is ≤5 meters, facilitating law enforcement operations.
  • Easier Operation: Modular design enables plug-and-play deployment for quick deployment.
  • High Stability: Supports 24/7 continuous operation with an availability of ≥99.9%.
Application Value
  • Airport Terminals: Prevent drones from interfering with air routes and avoiding aviation accidents.
  • Prison Examination Centers: Prevent drones from delivering contraband or engaging in cheating.
  • Large Events: Prevent drones from disrupting public order during sporting events, concerts, and exhibitions.
  • Energy facilities: Low-altitude protection for oil fields, power plants, and communications hubs, ensuring the safety of critical infrastructure.
  • Urban security: As a key node in the low-altitude surveillance network, it supports the development of smart city security.

The JDY-900(P) is more than just a device; it's a complete low-altitude security system, creating long-term, stable value for users.

Product Name Jdy-900(P) Anti-UAV Single-Station Defense System
Core Technology Passive Detection, Broadband Scanning
Detection Frequency 300MHz to 6000MHz; 300MHz to 9000MHz (select models)
Key Detection Frequency Bands 2.4GHz / 5.8GHz / 800MHz / 900MHz / 1.4GHz / 5.2GHz
Detection Range Jdy-900: 1 to 5km; Jdy-900p: 1 to 8km
Positioning Accuracy ≤10m (UAV); ≤5m (operator)
Interference Frequency Bands 2.4GHz / 5.8GHz / 900MHz / GPS / Beidou / Glonass / Galileo
Interference Range 1-3 km (depending on electromagnetic environment)
Interference Mode Four-sector directional/omnidirectional strike
Transmit Power 360W; 1500W (select models)
