JCVision 32-Inch Indoor Digital Signage Display – E-LED Backlit, Wide Viewing Angle, Wall Mount Light Box for Retail & Hospitality (HD-352C)
JCVision 32-Inch Indoor Digital Signage Display – E-LED Backlit, Wide Viewing Angle, Wall Mount Light Box for Retail & Hospitality (HD-352C)
JCVision 32-Inch Indoor Digital Signage Display – E-LED Backlit, Wide Viewing Angle, Wall Mount Light Box for Retail & Hospitality (HD-352C)
JCVision 32-Inch Indoor Digital Signage Display – E-LED Backlit, Wide Viewing Angle, Wall Mount Light Box for Retail & Hospitality (HD-352C)
JCVision 32-Inch Indoor Digital Signage Display – E-LED Backlit, Wide Viewing Angle, Wall Mount Light Box for Retail & Hospitality (HD-352C)
JCVision 32-Inch Indoor Digital Signage Display – E-LED Backlit, Wide Viewing Angle, Wall Mount Light Box for Retail & Hospitality (HD-352C)
Specifications
Brand Name :
JCVision
Model Number :
JC-32ILB
Certification :
CE ROHS
Place of Origin :
CHINA
MOQ :
1
Price :
600
Payment Terms :
T/T
Supply Ability :
50
Delivery Time :
5-8WORK DAYS
Packaging Details :
CARTON BOX
Brand :
JCVision
Model :
HD-352C
Product Name :
32" Wall Light Box (Square Edge
Screen Size :
32 inches
Backlight Type :
E-LED
Resolution :
3840 × 2160 (4K UHD)
Aspect Ratio :
16:9
Viewing Angle :
89° / 89° / 89° (L/R/U/D)
Display Colors :
16.7M
Brightness :
300 ± 20 cd/m²
Contrast Ratio :
1200:1
Response Time :
6 ms
Active Display Area :
698.40 × 392.85 mm (H × V)
Chipset :
Hisilicon Hi3751V352F Quad-Core, up to 1.0 GHz
GPU :
Mali-450 MP2
Operating System :
Android 9.0
RAM :
2 GB
Storage :
32 GB
Decoding Resolution :
Up to 4K @ 60Hz
Image Rotation :
0° / 90° / 180° / 270° manual
USB Ports :
2 × USB
HDMI :
1 × HDMI In
LVDS Interface :
1 × LVDS (single/dual channel, 6/8-bit), supports 3.3V/5V/12V
Ethernet :
RJ45 100M Ethernet
Wi-Fi :
2.4G (802.11 b/g/n)
4G Module :
Optional
Backlight Control :
Onboard 12V support
Video Formats :
MPEG4, MPEG2, MPEG1, WMV, TS, MOV, AVI, FLV, etc.
Audio Formats :
WAV, MP3, AAC, etc.
Image Formats :
JPEG, PNG, BMP, GIF, etc.
Speakers :
2 × 8Ω 3W
Power Input :
AC 100–230V, 50/60Hz
Power Consumption :
≤ 120W
Net Weight :
8.0 kg
Gross Weight :
10.0 kg
Carton Dimensions :
830 × 150 × 550 mm
Product Dimensions :
725.80 × 420.30 × 29.20 mm (including wall mount)
Installation :
Wall-mounted (Landscape / Portrait)
Operation :
24/7 Continuous Use
Description

Product Name: JCVision 32-Inch Indoor Digital Signage Display – E-LED Backlit, Wide Viewing Angle, Wall Mount Light Box for Retail & Hospitality (HD-352C)

Product Description:

Introducing the JCVision 32-inch Wall Light Box (Square Edge) – a compact yet powerful indoor digital signage solution perfect for retail stores, restaurants, hotels, and commercial environments where space is limited but visual impact matters.

The 32-inch E-LED backlit panel delivers 1920×1080 Full HD resolution with 300 cd/m² brightness, 1200:1 contrast ratio, and 89° ultra-wide viewing angles (L/R/U/D), ensuring clear and vibrant visuals from any direction. With a 6ms response time, it handles dynamic video content smoothly.

Powered by the Hisilicon Hi3751V352F quad-core chipset (up to 1 GHz) and Mali-450 MP2 GPU, the display runs on Android 9.0 with 2GB RAM and 32GB internal storage. It supports a wide range of video formats (MPEG4, MPEG2, WMV, MOV, AVI, etc.) and offers 1080P@60Hz video decoding.

Connectivity options include 2× USB, 1× HDMI IN, RJ45 Ethernet, and 2.4G Wi-Fi (802.11b/g/n). An optional 4G module is available for remote content management. The unit supports both horizontal and vertical wall mounting, making it ideal for digital menu boards, promotional displays, signage, and information kiosks.

Key Specifications:

  • Screen Size: 32 inch

  • Resolution: 1920×1080

  • Brightness: 300±20 cd/m²

  • Response Time: 6ms

  • OS: Android 9.0

  • RAM / Storage: 2GB / 32GB

  • Power: ≤120W

  • Dimensions (with wall mount): 725.80 × 420.30 × 29.20 mm

  • Weight: 8.0 kg (net)
