Digital LCD Video Wall Display Splicing Screens Display 3x3 Video Wall Controller 49inch
Digital LCD Video Wall Display Splicing Screens Display 3x3 Video Wall Controller 49inch
Digital LCD Video Wall Display Splicing Screens Display 3x3 Video Wall Controller 49inch
Digital LCD Video Wall Display Splicing Screens Display 3x3 Video Wall Controller 49inch
Digital LCD Video Wall Display Splicing Screens Display 3x3 Video Wall Controller 49inch
Digital LCD Video Wall Display Splicing Screens Display 3x3 Video Wall Controller 49inch
Digital LCD Video Wall Display Splicing Screens Display 3x3 Video Wall Controller 49inch
Digital LCD Video Wall Display Splicing Screens Display 3x3 Video Wall Controller 49inch
Specifications
Brand Name :
JCVISION
Model Number :
JC-VW490
Certification :
CE, Rohs, FCC
Place of Origin :
SHENZHEN, CHINA
MOQ :
1unit
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
1000 Unit/Units per Month
Delivery Time :
5-8 work days
Packaging Details :
wooden box
Pixel Pitch :
0.248(H)x0.745(V)mm
Input Voltage :
AC100~240V 50/60Hz
Viewing Angle :
89/89/89/89
Contrast Ratio :
4000:1
Brightness :
500cd/m2
Response Time :
8ms
Operating system :
Stand-alone / android / win (option)
Ultra-narrow border :
0.88/1.8/3.5/5.5mm (Option)
Description

JCVISION 49inch LCD Advertising Machine Splicing Screens Display 3x3 Video Wall Controller

Features

1. Full hardware architecture, professional splicing chip design without CPU and operating system
2. Multi-line parallel processing with powerful processing functions;
3. Integrated multiple video signal sources
4. Can open the underlying communication protocol, which is convenient for users to flexibly adopt third-party central control, system or self-programmed software to construct a large screen engineering system
5. Embedded firmware intelligent upgrade system.
6. Narrow border full metal frame design
7. Fully silent industrial fan with automatic temperature switch
8. With 3D noise reduction, 3D filtering, 3D deinterlacing
9. Comes with a large screen splicing piece, a healthy splicing, easy to use
10. With energy saving, environmental protection, no radiation, support 7 * 24 hours of uninterrupted work, adapt to a variety of working environments that need to be turned on for a long time
11. Uniform brightness, stable image, no flicker, no distortion
12. Applicable to: commercial institutions, large shopping malls, specialty stores, franchise stores, hypermarkets, star hotels, restaurants, travel agencies, drug stores, etc.

Model
LG 49 inch 3.5MM splicing unit specifications
Diagonal display
49 "
Display area
1073.8 (W) *604.0(H)mm
Zoom
led Backlight
Panel Type
LED backlight
Resolution
1920(RGB)X1080, FHD
Spacing
0.1864 (H) * 0.5593 (V)
brightness
450CD / M²
Contrast
1300: 1
Color display
16.7M
response time
8ms
Viewing angle
89/89/89/89(Typ)
working frequency
60HZ
Patchwork stitching
3.5mm
USB input
(USB * 1) can be upgraded media player supports video pictures
HDTV input
(HDTV * 1) * Support 1920 1080 @ 60HZ signal input is backward
compatible with 4K be customized
VGA Entry
(VGA * 1) * Support 1920 1080 @ 60HZ signal inputs can be
backward compatible
DVI Entry
(DVI * 1) * Support 1920 1080 @ 60HZ signal inputs can be backward
compatible 4K be customized
BNC Entry
(BNC * 1)And other standard support NTSC PAL
Remote control receiver input
(DEBUG * 1) the remote control signal transmission
RJ45 input
(RJ45 * 1) RS232 input signal
RJ45 output
(RJ45 * 2) RS232 signal output
BNC output
(BNC * 1)And other standard support NTSC PAL
Operating Voltage
AC220V 50 / 60Hz
Power consumption
≤240W
Standby power consumption
3W
Operating temperature
0~ 50 C
storage temperature
-20~ 65 C
Menu language
Simplified Chinese, Traditional Chinese, English and other languages
Installation mode
Wall-mounted, embedded, floor, before the maintenance, cabinet
