Twin Screw Extruder for Degradable Agricultural Film Plastic Raw Material Granulation
Twin Screw Extruder for Degradable Agricultural Film Plastic Raw Material Granulation
Twin Screw Extruder for Degradable Agricultural Film Plastic Raw Material Granulation
Twin Screw Extruder for Degradable Agricultural Film Plastic Raw Material Granulation
Twin Screw Extruder for Degradable Agricultural Film Plastic Raw Material Granulation
Twin Screw Extruder for Degradable Agricultural Film Plastic Raw Material Granulation
Specifications
Place of Origin :
Dongguan, Guangdong, China
After-sales Service :
Installation and Commissioning Included
Brand Name :
JCD
Payment Terms :
T/T,Western Union
Number of Screws :
Twin Screws
Parameter Customization :
Customizable According to Requirements
Delivery Time :
35 working days
Screen Changing Method :
Multiple Screen Changing Methods
Applicable Raw Materials :
PVC、PET、PS、EVA、ABS、PE、PP
Product Alias :
Pelletizing Machine
Barrel Material :
Bimetallic Wear-resistant
Supply Ability :
20 sets per month
Pelletizing Method :
Multiple Feeding Forms
MOQ :
1
Price :
To be Quoted
Product Use :
Lab R&D Plastic Pelletizing
Application Scope :
Lab R&D Plastic Modification, Masterbatch Production
Description

Twin Screw Extruder for Degradable Agricultural Film Plastic Raw Material Granulation

Twin Screw Extruder for Degradable Agricultural Film Plastic Raw Material Granulation

Product Overview

This JCD20 lab twin screw extruder is specially designed for lab-scale formula testing, new material R&D and small-batch sample production, featuring a compact modular design with high precision and flexible configuration. With a 22mm screw diameter and output range of 3-30kg/h, it balances experimental precision and small-scale production capacity, perfectly matching the needs of plastic formula debugging, material performance testing and small-batch trial production in universities, research institutes and enterprise R&D departments. Equipped with high-precision temperature control, miniaturized core components and an intuitive control system, the bimetallic wear-resistant barrel and low-noise transmission box ensure accurate, stable and quiet operation, making it a reliable experimental tool for material science research and product development.

Technical Specifications

Model Diameter(mm) Max.L/D Speed(rpm) Power(kw) Output(kg/h)
JCD16 16 68 600 1.5/2.2 1~5
JCD20B 22 68 600 3/4 3~10
JCD20C 22 68 600 5.5/7.5 5~20
JCD20D 22 68 600 7.5/11 10~30
JCD26B 26 68 600 5.5/7.5 5~20
JCD26C 26 68 600 11/15 10~40
JCD26D 26 68 600 15/18.5 20~60
JCD30B 30.2 68 600 7.5/11 10~30
JCD30C 30.2 68 600 18.5/22 20~60
JCD30D 30.2 68 600 22/30 40~100
JCD35B 35.6 68 600 15/18.5 20~50
JCD35C 35.6 68 600 30/37 60~100
JCD35D 35.6 68 600 37/45 100~150
JCD40B 41 68 600 15/18.5 20~50
JCD40C 41 68 600 30/37 80~120
JCD40D 41 68 600 37/45 100~180
Note: All parameters can be customized according to lab R&D requirements.

Twin Screw Extruder for Degradable Agricultural Film Plastic Raw Material Granulation

Core Features & Advantages

  • Compact & Space-saving Design
    The 22mm screw and compact frame occupy minimal bench space, fitting seamlessly into laboratory workstations and small R&D environments.
  • High-precision & Stable Processing
    Equipped with a closed-loop temperature control system and real-time torque monitoring, it ensures uniform material plasticizing and mixing, providing reliable experimental data for formula optimization.
  • Flexible Modular Configuration
    Screw elements and barrel sections can be quickly disassembled and replaced, supporting rapid switching of different material formulas and process parameters for efficient multi-group experiments.
  • Low-noise & User-friendly Operation
    The integrated low-noise transmission system and intuitive control panel ensure quiet operation and easy handling, suitable for long-duration experimental testing in labs.
  • Multi-functional Supporting Systems
    Configurable with a mini vacuum exhaust unit, micro screen changer and optional pelletizing modules (water-cooled strand pelletizing, air-cooled hot cutting), meeting diverse lab sample preparation needs.
  • Wear-resistant & Durable
    Barrel and screw adopt bimetallic wear-resistant materials, ensuring long service life even with frequent material switching and experimental cycles.

Twin Screw Extruder for Degradable Agricultural Film Plastic Raw Material Granulation

Product Applications

This JCD20 lab twin screw extruder is ideal for small-scale material research and experimental production, widely used in the following scenarios:
  • Plastic Formula R&D: Testing reinforced, filled and functional modification formulas of PP/PE/PS/EVA and other general plastics.
  • New Material Development: Experimental processing of biodegradable plastics, specialty polymers and composite materials.
  • Academic Research & Teaching: Plastic processing experiments in universities, material performance research in scientific institutes.
  • Enterprise R&D: Small-batch trial production of new products, verifying process feasibility before mass production.
  • Masterbatch Sample Preparation: Small-volume production of color masterbatch, flame retardant masterbatch and functional masterbatch for formula verification.
