R210-7 Sun Shaft XKAH-00017 Hyundai R210-7 XKAY-00448 Motor Shaft Travel
R210-7 Sun Shaft XKAH-00017 Hyundai R210-7 XKAY-00448 Motor Shaft Travel
R210-7 Sun Shaft XKAH-00017 Hyundai R210-7 XKAY-00448 Motor Shaft Travel
R210-7 Sun Shaft XKAH-00017 Hyundai R210-7 XKAY-00448 Motor Shaft Travel
R210-7 Sun Shaft XKAH-00017 Hyundai R210-7 XKAY-00448 Motor Shaft Travel
R210-7 Sun Shaft XKAH-00017 Hyundai R210-7 XKAY-00448 Motor Shaft Travel
R210-7 Sun Shaft XKAH-00017 Hyundai R210-7 XKAY-00448 Motor Shaft Travel
R210-7 Sun Shaft XKAH-00017 Hyundai R210-7 XKAY-00448 Motor Shaft Travel
Specifications
Brand Name :
PNC
Model Number :
R210-7
Place of Origin :
China
MOQ :
1set
Price :
USD 20-40/PC
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
1000pcs/months
Delivery Time :
1-3 working days
Packaging Details :
Carton box
Machine :
Hyundai 7-Series Crawler Excavator
Model :
R140LC-7, R180LC7, R210LC7, R210NLC7
Part No. :
XKAH-00017, XKAY-00448
Weight :
1-3kgs
Warranty :
3 months
Product name :
R210-7 Sun Shaft, R210-7 Sun Gear
Description

R210-7 Sun Shaft XKAH-00017 Hyundai R210-7 XKAY-00448 Motor Shaft Travel

Description

R210-7 Sun Shaft, R210-7 Sun Gear, R210-7 Motor Shaft

Application

Hyundai 7-Series Crawler Excavator

Model

 R140LC-7, R180LC7, R210LC7, R210NLC7

Part No.

XKAH-00017, XKAY-00448

Quality

OEM quality, China made

Weight

1-3kgs

Packing

Light items pack with carton box, heavy items pack into wooden case

MOQ

1PC

Lead time

About 1-3 working days

Payment

TT, Western union, Paypal, Paysend, RMB

Warranty

3 Months

Shipping Port

Huangpu Old Port, Shenzhen Yantian,Guangzhou

R210-7 Sun Shaft XKAH-00017 Hyundai R210-7 XKAY-00448 Motor Shaft Travel

Parts on group TRAVEL REDUCTION GEAR(-#2078, TYPE 1):

Pos. Part No Qty Parts name Comments
*. XKAH-00112 [1] REDUCTION GEAR SEE 4150
*. XKAH-00312 [1] REDUCTION GEAR SEE 4150
*. XKAH-00452 [1] REDUCTION GEAR SEE 4310
*. XKAH-00312 [1] REDUCTION GEAR SEE 4150
1. XKAH-00001 [1] HUB SEE 4150
1. XKAH-00311 [1] HUB SEE 4150
N1. XKAH-00451 [1] HUB SEE 4310
1. XKAH-00311 [1] HUB SEE 4150
*-1. XKAH-00002 [1] SPINDLE KIT
*-11. XKAH-00003 [1] SPINDLE ASSY
N2. XKAH-00004 [1] SPINDLE
N3. XKAH-00005 [1] HOLDER-FLANGE
19. XKAH-00006 [3] BOLT-SOCKET
34. XKAH-00007 [6] PIN-PARALLEL
37. XKAH-00008 [3] WASHER-PLAIN
*-2. XKAH-00371 [1] RV GEAR ASSY
*-21. XKAH-00010 [1] RV GEAR KIT
4. XKAH-00011 [1] RV GEAR-A
5. XKAH-00012 [1] RV GEAR-B
9. XKAH-00013 [3] SHAFT-CRANK
12. XKAH-00014 [6] SPACER
22. XKAH-00015 [6] BEARING-T/ROLLER
23. XKAH-00016 [6] BEARING-NEEDLE
6. XKAH-00017 [1] INPUT GEAR
*-3. XKAH-00018 [1] GEAR-SPUR KIT
7. XKAH-00019 [3] GEAR-SPUR
8. XKAH-00020 [1] COVER
13. @ [3] PIECE-DISTANCE
13-1. XKAH-00850 [AR] PIECE(3.75-3.80T)
13-2. XKAH-00851 [AR] PIECE(3.80-3.85T)
13-3. XKAH-00852 [AR] PIECE(3.85-3.90T)
13-4. XKAH-00853 [AR] PIECE(3.90-3.95T)
13-5. XKAH-00854 [AR] PIECE(3.95-4.00T)
15. XKAH-00022 [1] COUPLING
17. XKAH-00023 [24] PIN
20. XKAH-00024 [3] RING-SNAP
21. XKAH-00025 [2] BEARING-BALL
25. XKAH-00026 [3] RING-SNAP
K27. XKAH-00027 [2] O-RING
K29. XKAH-00028 [1] O-RING
K30. XKAH-00029 [1] O-RING
*-4. XKAH-00372 [1] FLOATING SEAL KIT
KN31. XKAH-00031 [2] SEAL-FLOATING
33. XKAH-00032 [3] PLUG-RO
35. XKAH-00110 [12] BOLT-SOCKET
36. XKAH-00033 [1] BALL-STEEL
42. XKAH-00034 [2] PIN-PARALLEL
K43. XKAH-00035 [3] O-RING
N. @ [AR] NOT SUPPLIED PARTS
K. XKAH-00111 [1] SEAL KIT SEE ILLUST

R210-7 Sun Shaft XKAH-00017 Hyundai R210-7 XKAY-00448 Motor Shaft Travel
