JC-800 Model 2-Ton Horizontal Transformer Winding Machine with PLC and Servo Motor System and Double Head Electric Magnetic Powder Tension Pay-off Rack

Specifications

MOQ :

Price :

3000

Model NO. :

S30

Outer Diameter :

< 600mm

Axial Height :

<800mm

Coil Form :

Circular, Oblong, Elliptical, Rectangular

Wire Specification :

Enameled Wire

Dimensions :

900*900*900

Production Capacity :

60000PCS/Year

Winding Speed :

0-280r/min

Total Power :

5KW

Wire Diameter :

Φ 0.3 to Φ 4mm

Flat Wire Size :

≤ 3x12mm

Bearing Shaft :

Φ 36x450mm

Control System :

PLC and servo motor

Payoff Rack :

Double ended flat wire and round wires

Weight Capacity :

2-Ton

Description

Purpose:

This equipment is suitable for winding circular, elliptical, oblong, rectangular power transformers, transformers, reactances.
The control part of the device coil adopts a PLC and servo motor system, which has a high level of automation and is particularly suitable for the winding production of amorphous high-voltage coils.
Model/Parameter: JC-800

Outer diameter of wire coil: ≤ 600mm

Axial height of coil: ≤ 800mm

Coil form: circular, oblong, elliptical, rectangular

Wire specification: enameled wire( Φ 0.3 to Φ 4mm), flat wire ≤ 3x12mm

Payoff rack: double ended flat wire and a set of round wires

Payoff frame material bearing shaft: Φ 36x450mm

Winding speed: 0-280r/min

Total power: 5KW
