32Inch FHD Lcd High Brightness Tft Display Commercial 2000Nits Tft Lcd Digital Color Monitor
32Inch FHD Lcd High Brightness Tft Display Commercial 2000Nits Tft Lcd Digital Color Monitor
Specifications
Model Number :
JB320GL02-D2000
Place of Origin :
China
MOQ :
1
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
3000pcs/month
Delivery Time :
8-10 working days
Packaging Details :
carton box
Size :
32inch
Resolution :
1920*1080
View Angle :
89/89/89/89 (Typ.)(CR≥10)
Signal Interface :
LVDS (2 ch, 8-bit) , 51 pins Connector
Operating Temp :
-20 ~ 60 °C
Storage Temp :
-20 ~ 60 °C
Application :
Digital Signage
Description

32Inch FHD Lcd Panel with Brightness 2000Nits JB320GL02-D2000 for Commercial Application

JB320GL02-D2000 is a color active matrix TFT LCD Module

(Thin Film Transistors) as an active switching devices. This open cell has a 31.51 inch
diagonally measured active area with FHD resolutions (1920 horizontal by 1080 vertical
pixel array). Each pixel is divided into RED, GREEN, BLUE dots which are arranged in
vertical stripe and this open cell can display 16.7M colors. The TFT-LCD panel used for
this open cell is adapted for a low reflection and higher color type.
1.2 Features
 LVDS interface with 2 pixel / clock
 High-speed response
 Low color shift image quality
 8-bit color depth, display 16.7M colors
 High luminance and contrast ratio, low reflection and wide viewing angle
 DE (Data Enable) only mode
 ADS technology is applied for high display quality
 RoHS compliant
