FCK MILLING SCROLL CHUCK
FCK MILLING SCROLL CHUCK
Specifications
Brand Name :
NTH
Model Number :
FCK-06,FCK-08，FCK-10
Place of Origin :
CHINA
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
1000 sets/M
Delivery Time :
3 work days available
Packaging Details :
Good and firm package is suitable for sea and air shipping
Product name :
FCK MILLING SCROLL CHUCK
Material :
Forged steel
Usage :
Gripping/Fixture
Feature :
High precision/High quality
Size :
Refer to the specification
Service :
OEM/ODM is acceptable
Description

FCK MILLING SCROLL CHUCK

BAND:NTH

MILLING CHUCK ADVANTAGES

1. The handle is at a 30 degree angle with the chuck surface, it makes the operation more convenient.

2. The super thin design is for reserving more processing space.

3. The chuck flange with U type home by which is easy for mounting onto milling workbench.

4. Two-piece jaws structure, it can use hard jaws and soft jaws for different clamping requirements.

FCK MILLING SCROLL CHUCK

Unit:mm

MODEL/SPEC OD. Clamping Range
mm		 ID. Clamping Range
mm		 Weight
kg		 A1 A2 B1 B2
FCK-06 Ø8-Ø160 Ø48-Ø150 10.6 220 170 58 18
FCK-08 Ø11-Ø200 Ø62-Ø190 18.1 270 210 65 20
FCK-10 Ø12-Ø250 Ø72-Ø240 27.9 315 255 73 20
FCK-12 Ø15-Ø300 Ø86-Ø290 42.9 370 305 80 22
FCK-14 Ø45-Ø304 Ø115-Ø284 48 420 356 80 23
FCK-16 Ø80-Ø344 Ø174-Ø318 77 470 400 92 24
FCK-20 Ø90-Ø409 Ø212-Ø371 126 570 500 105 26

MODEL/SPEC C D E F G H J K L M
FCK-06 130 147 45 6 3-M10x1.5P 67 25 40.5 10 13
FCK-08 155 172 60 6 3-M10x1.5P 80 30 42 11 13
FCK-10 190 210 80 6 3-M12x1.75P 92 36 54.5 12 16
FCK-12 250 285 105 5 3-M12x1.75P 110 42 56 14 18
FCK-14 - 330 130 5 M12 110 42 70.5 14 18
FCK-16 - 365 160 6 M16 130 45 75 15 18
FCK-20 - 465 220 7 M16 166 50 84 17 1

Subject to technology changes without prior information
Non-standard requirements can be made
