Specifications
Brand Name :
ITI-LINK
Model Number :
ITI-CTF8-019
Certification :
UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS
Place of Origin :
SHENZHEN
MOQ :
1000pcs
Price :
50$-100$
Payment Terms :
T/T
Supply Ability :
800pcs/day
Delivery Time :
15-45 Days
Packaging Details :
Wooden shaft packaging 40*26*20cm Outer box size：42*42*22cm
Length :
1000 Ft
Conductor Gauge :
22 AWG
Jacket Material :
LSZH/PVC
Jacket Color :
Red
Shielding :
FTP
Bandwidth :
2000 MHz
Conductor Material :
Copper
Cable Category :
CAT8
Description

CAT8 FFTP Cable 22AWG Solid Copper 1000Ft — 40Gbps Data Center Cable

Product Description:

Engineered for mission-critical networks, the ITI-LINK CAT8 F/FTP Cable (ITI-CTF8-019) combines 22AWG solid copper conductors, pair-and-overall foil shielding, and a rugged PVC/PE or optional LSZH jacket. Supports 40Gbps performance up to 30m and comes on a 1000Ft reel — perfect for backbone runs, rack-to-rack connections, and industrial Ethernet. Red jacket ensures easy cable management.

  1. Product Overview:The ITI-LINK CAT8 F/FTP Shielded LAN Cable (ITI-CTF8-019) delivers enterprise-grade 40Gbps performance on a 1000Ft spool. Designed for high-speed, short-reach data center and industrial applications.
  2. Performance:Supports frequencies to 2000MHz and data rates up to 40Gbps (optimal for up to 30m at full spec). The solid 22AWG conductor profile delivers lower DC resistance and improved return loss versus stranded alternatives.
  3. Structure & Materials:Each twisted pair is wrapped in aluminum foil (pair-level) with an additional overall foil shield (F/FTP) to form a robust barrier against EMI. Conductors are solid oxygen-free copper, and the outer jacket is PVC/PE with LSZH available. Color: Red for rapid visual identification in dense cabling environments.
  4. Application Value:Use as a primary Data Center Cable for switch-to-switch, switch-to-server, or high-bandwidth appliance links. Also excellent for Industrial Network Cable use where electrical noise from machinery demands a Shielded LAN Cable solution.
  5. Brand Trust:Model ITI-CTF8-019 by ITI-LINK — consistent manufacturing, 1000Ft convenience, and materials chosen for long-term reliability.



Technical Parameters:

Product Description:

Rev.: A ECN Description:
Construction Item Description Electrical Property


Conductor


Material

Bare Solid Copper(elongation:

19-24%)

 Conductor Resistance at 20°C ≤ 5.6 Ω / 100m
OD 22 AWG Resistance unbalance within a pair ≤ 0.2%






Insulation

 Material PE Skin-Foam-Skin Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V


>1500 MΩ / 100m
OD 1.62 ±0.01 mm Mutual capacitance 5600 pF / 100m MAX
Average THK 0.50 mm Capacitance unbalance pair to ground at 800Hz or 1 kHz ≤ 160 pF / 100m



Color

 1p: white + 2 blue stripes & blue Characteristic impedance at 100MHz 100 ± 15 Ω

2p: white + 2 orange stripes &

orange

Dielectric Strength Test Voltage (cd/cd,cd/screen): 1.00KV DC or

0.7 KV AC for 1 min


No breakdown
3p: white + 2 green stripes & green Mechanical Property
4p: white + 2 brown stripes & brown



insulation

 elongation before aging ≥ 200%



Pair Twist



Lay & Direction

 1p: S=19.0 mm (28%) tensile strength before aging ≥10 MPa
2p: S=23.5 mm (31%) elongation after aging ≥ 150%
3p: S=21.5 mm (33%) tensile strength after aging ≥8 MPa
4p: S=25.0 mm (36%)



jacket

 elongation before aging ≥ 150 %
OD / tensile strength before aging ≥ 13.5 MPa


Inner Assemble

 Lay S=90 ± 5 mm elongation after aging ≥ 125 %
Direction according to the drawing tensile strength after aging ≥ 12.5 MPa
OD / Packing


Filler

 Ripcord / NA NA
Drain Wire /



Pair Shield

 Shield Pair Shield



Construction /
Material Polyester/Aluminium (PET/ALU)
Coverage ≥ 200%


Braid

 Material AL-MG
Coverage ≥ 40%





Jacket

 Material PVC, 50P, -20~75℃
Hardness 81± 3
OD 8.6 ± 0.2
Average THK 0.65


Color

 orange
Marking Color black
Marking

according to the customer's

requirements






Applications:

  1. Data Center Cable: switch-to-switch, server uplinks, top-of-rack and splice runs where 40Gbps speed and F/FTP shielding are required.
  2. Industrial Network Cable: factory floor and automation networks exposed to electrical noise; robust shielding reduces packet errors.
  3. Enterprise Backbone: high-density wiring closets, backbone trunks and rack interconnects.
  4. High-Performance Home/Office: media servers, NAS, gaming rigs requiring ultra-low latency.
