Tie rod ends transmit steering force to the steering knuckles, allowing suspension movement while maintaining precise steering control in ISUZU CXZ and FVR trucks.

The Tie Rod End Set (OEM Numbers: 1-43150736-1 RH / 1-43150737-1 LH / 1431507361 / 1431507371) is a premium-quality, direct replacement steering component designed specifically for ISUZU CXZ and FVR series heavy-duty trucks. This set includes both the right-hand (RH) and left-hand (LH) tie rod ends, which connect the steering linkage to the steering knuckles. They transmit steering force from the drag link or relay rod while allowing the suspension to move up and down. These are critical safety components that directly affect steering response, vehicle stability, and tire wear.

• OE Quality: Manufactured to strict ISUZU dimensional and material specifications for perfect fit and function.
• Forged Alloy Steel Housing: High-strength construction withstands heavy steering loads and road shock.
• Hardened Ball Stud: Precision-ground and heat-treated for smooth articulation and wear resistance.
• Durable Dust Boot: Rubber boot retains grease and blocks dirt, water, and contaminants.
• Restores Steering Precision: Eliminates steering play, shimmy, and vague response caused by worn tie rod ends.
• Improves Safety: Maintains proper steering linkage connection for reliable vehicle control.
• Reduces Tire Wear: Correct steering geometry prevents uneven and premature tire wear.
• Direct Replacement: Matches OE mounting taper, thread size, and overall dimensions.
• Long Service Life: Engineered for heavy-duty commercial truck applications.
• Complete Set: Includes both RH and LH tie rod ends for a complete front-end service.

This tie rod end set is specifically designed for ISUZU heavy-duty trucks and commercial vehicles. Common applications include:

• ISUZU CXZ (Heavy-Duty Trucks)
• ISUZU FVR (Heavy-Duty Trucks)
• Engine Applications: ISUZU Diesel Engines (verify with VIN - engine independent steering component)
• Also compatible with various ISUZU models using the same steering linkage configuration

Professional mechanic or steering specialist installation is strongly recommended:

1. Ensure vehicle is safely raised - Use appropriate jack stands or a lift to support the front axle.
2. Remove the front wheels - Remove both front wheels for access to the steering linkage.
3. Loosen the jam nuts - Loosen the tie rod adjusting sleeve jam nuts (count threads before removal for approximate alignment).
4. Remove the cotter pins and nuts - Remove the cotter pins and castle nuts from the ball studs.
5. Separate the ball studs - Use a proper tie rod end puller or ball joint separator; do not hammer directly on the studs.
6. Remove the old tie rod ends - Unscrew the tie rod ends from the adjusting sleeves; note the number of turns.
7. Clean the threads - Clean the adjusting sleeve threads and inspect for damage.
8. Install the new tie rod ends - Screw the new RH and LH tie rod ends into the adjusting sleeves to the same approximate positions.
9. Install the ball studs - Insert the ball studs into the steering knuckles; install castle nuts and torque to specification.
10. Install new cotter pins - Secure the castle nuts with new cotter pins.
11. Tighten the jam nuts - Tighten the jam nuts against the adjusting sleeves.
12. Reinstall the wheels - Install the wheels and torque lug nuts to specification.
13. Check toe setting - A professional wheel alignment is required after installation.
14. Road test - Test drive to verify proper steering response, no play, and no abnormal noise.

• Material Verification: Confirms forged alloy steel composition meets ISUZU strength and durability specifications.
• Dimensional Inspection: Ball stud taper, thread size, length, and mounting dimensions verified within OEM tolerances.
• Hardness Testing: Ball stud and bearing surfaces tested for proper wear resistance.
• Articulation Testing: Ball stud movement checked for smooth, consistent operation.
• Boot Integrity Inspection: Dust boot checked for proper fit and sealing.
• Visual Inspection: 100% checked for cracks, thread damage, or manufacturing defects.
• Packaged Safely: Protected and packaged to prevent damage during transit.

• Neutral export packing or customized packaging available
• Carton or wooden case for safe transportation
• Fast delivery for stock items
• Shipping by Express Air or Sea
