OEM 94600-6A900 Throttle Position Sensor for HYUNDAI Universe 12.0L Diesel Engine with Potentiometric 3-Wire Design
OEM 94600-6A900 Throttle Position Sensor for HYUNDAI Universe 12.0L Diesel Engine with Potentiometric 3-Wire Design
OEM 94600-6A900 Throttle Position Sensor for HYUNDAI Universe 12.0L Diesel Engine with Potentiometric 3-Wire Design
OEM 94600-6A900 Throttle Position Sensor for HYUNDAI Universe 12.0L Diesel Engine with Potentiometric 3-Wire Design
OEM 94600-6A900 Throttle Position Sensor for HYUNDAI Universe 12.0L Diesel Engine with Potentiometric 3-Wire Design
OEM 94600-6A900 Throttle Position Sensor for HYUNDAI Universe 12.0L Diesel Engine with Potentiometric 3-Wire Design
Specifications
Brand Name :
YIMI
Model Number :
HYUNDAI Universe Space Luxury Noble Bus 12L Diesel
Certification :
ISO/TS16949
Place of Origin :
China
MOQ :
5 pcs
Price :
Negotiable
Payment Terms :
T/T,Western Union
Supply Ability :
10000 pcs/month
Delivery Time :
5-8 Work Days
Packaging Details :
Neutral Package or as customers’ request
Output Signal :
Analog voltage (0.5V – 4.5V)
Supply Voltage :
5V DC
Resistance :
2.0 kΩ ±20%
Linearity Error :
< ±1.5%
Operating Temperature :
–40°C to +125°C
Housing Material :
PBT/GF30
Connector Type :
3‑pin female
Mounting :
Two screws (M4×20)
Description
4600-6A900 Throttle Position Sensor for HYUNDAI Universe Space Luxury Noble Bus 12L Diesel
The Throttle Position Sensor (TPS) with OEM number 94600-6A900 is a verified direct-fit replacement for the HYUNDAI Universe series luxury intercity coaches, specifically the Space Luxury and Space Noble trim levels. This critical component converts the mechanical position of the throttle valve into a variable voltage signal for the Engine Control Unit (ECU), ensuring proper fuel injection, timing, and transmission shift points.
OEM 94600-6A900 Throttle Position Sensor for HYUNDAI Universe 12.0L Diesel Engine with Potentiometric 3-Wire Design
Part Number: 4600-6A900 | Product Name: Throttle Position Sensor
Car Model: HYUNDAI Universe Space Luxury Noble Bus | Engine Model: D6HA D6GA
Condition: 100% Brand New | Origin: China Mainland
Main Market: Middle East, Asia, Africa, South America, North America & Europe
Package: Neutral Packing Or Make It As Requested
Material: High-strength aluminum alloy & precision bearings
Installation: Direct OEM replacement | Quality Standard: OEM equivalent / ISO quality control
Performance Specifications
  • Real Shop Test Data
    Output voltage range: 0.5V ±0.1V at idle to 4.5V ±0.1V at wide-open throttle
    Operating resistance: 1.5 kΩ – 3.0 kΩ across sweep range
  • Proven Durability
    Rated service life: 500,000 km under normal coach operating conditions
    Operating temperature: –40°C to +125°C
  • Installation Success Rate
    99% direct bolt-on fitment for Hyundai Universe models
Vehicle & Engine Compatibility
Compatible Engine Models:
• Hyundai Q-series — 12.0L inline-6 turbo diesel (Q300, Q370, Q420)
• Hyundai D6HA — 12.0L, Euro 5/6 emissions
• Hyundai D6GA — 12.0L, updated generation

Compatible Vehicle Models:
• HYUNDAI Universe (2010–2018) — Space Luxury trim
• HYUNDAI Universe (2018–present) — Space Noble trim
• Hyundai Universe Xpress Luxury (verify with OEM parts catalog)

Not compatible with: Hyundai passenger cars, light trucks, or older buses with cable-operated throttles.
Features & Benefits
Feature Benefit + Verification
Precision resistive track with conductive plastic Smooth voltage transition — eliminates dead spots that cause surging or limp mode
Weather-sealed housing Withstands under-bus conditions — dust, moisture, and road salt tested
OEM-correct connector and pinout Plug-and-play installation — no wiring modifications required
Wide operating temperature range (–40°C to +125°C) Reliable in extreme climates — from frozen northern routes to desert heat
Direct bolt-on fit 30-minute replacement — includes mounting screws and gasket
100% functional test Each sensor tested on programmable throttle body simulator
Quality Control & Verification
QC Item Verification Method
Output voltage at closed throttle 0.50V ±0.05V (after zero-point calibration)
Output voltage at WOT 4.50V ±0.10V
Linearity error Error from best-fit line < ±1.5%
Hysteresis Voltage difference < 20mV at mid-point
Contact resistance < 100Ω variation across sweep
Thermal drift Output voltage shift < ±0.05V
Vibration endurance ISO 16750-3, 10g, 10–2000 Hz, 24 hours — no failure
Installation & Maintenance
Critical notes for HYUNDAI Universe bus TPS replacement:
Verify correct part compatibility, check for throttle body wear, inspect wiring harness, and clear existing DTCs after installation.
Installation Steps
  1. Disconnect battery negative terminal and wait 5 minutes
  2. Locate TPS on throttle body
  3. Remove electrical connector and mounting screws
  4. Gently lift old TPS off throttle shaft
  5. Compare new TPS shaft slot alignment
  6. Install new TPS with provided gasket/O-ring
  7. Torque mounting screws to 2–3 Nm
  8. Reconnect electrical connector and battery
  9. Perform TPS relearn procedure
  10. Verify voltage readings with scan tool
Packaging & Supply
  • Individually sealed in anti-static bag with protective cap
  • Packed in foam-lined carton
  • Mounting screws and gasket included
  • Bulk wholesale: 20 sensors per master carton
  • Shipping dimensions: 12*10*6 cm, weight ~0.1 kg
Inquiry & Ordering
For Throttle Position Sensor 94600-6A900 for HYUNDAI Universe Space Luxury / Noble Bus:
  • ✔️ Wholesale price for bus fleets, service centers, distributors
  • ✔️ Single unit sample (test fitment and voltage output)
  • ✔️ Bulk order discount & custom packaging
  • ✔️ Test video (voltage sweep) & QC report
Please provide your quantity, destination port, and vehicle specifics (model year, VIN, or photo of original sensor) for accurate fitment verification.
