Specifications
Engine Displacement :
3.9L (3856cc)
Material :
Centrifugally cast high-alloy cast iron
Model Number :
ISUZU NPR66
Part Number :
5-87813332-0, 5878133320
Packaging Details :
Neutral Package or as customers’ request
Certification :
ISO/TS16949
Payment Terms :
T/T,Western Union
Supply Ability :
10000 pcs/month
Cooling Type :
Engine coolant circulation
Place of Origin :
China
Liner Type :
Wet type (with O-rings)
Quantity per Set :
4 liners
MOQ :
10 pcs
Stroke Length :
118 mm
Delivery Time :
5-8 Work Days
Price :
Negotiable
Bore Size :
102 mm
Brand Name :
YIMI
Description
Cylinder Liner Set 5-87813332-0 For Isuzu NPR66 4HF1 Engine
Premium-quality cylinder liner set designed specifically for Isuzu NPR66 medium-duty trucks with 4HF1 diesel engines.
Product Overview
Function: Engine cylinder liner set (wet liners) provides durable, replaceable wear surfaces for piston rings. Restores compression, reduces oil consumption, and extends engine life for Isuzu 4HF1 diesel engines.
Part Number 5-87813332-0, 5878133320
Product Name Cylinder Liner Set / Engine Cylinder Sleeve Set
Car Model ISUZU NPR66
Engine Model ISUZU 4HF1 (3.9L Diesel)
Condition 100% Brand New
Material High-strength aluminum alloy & precision bearings
Warranty 6 Months
Wet Type Cylinder Liner Set with O-rings for Isuzu NPR66 4HF1 Engine - Centrifugally Cast High-Alloy Cast Iron Direct OEM Replacement
Features & Advantages
  • OE Quality: Manufactured to Isuzu dimensional and material specifications for perfect fit and long service life
  • Complete Set: Includes 4 liners - no need to order individually
  • Centrifugal Casting: Dense, uniform grain structure for high strength and wear resistance
  • Precision Machined: Accurate bore size, roundness, and surface finish
  • Plateau Honed: Optimized finish for immediate ring seating
  • Corrosion Resistant: Alloy resists cavitation erosion in wet liner applications
  • Restores Engine Performance: Eliminates blow-by, low compression, and high oil consumption
  • Direct Replacement: Drop-in or press-fit installation
  • Cost-Effective: Affordable alternative to genuine OEM liners
Vehicle & Engine Compatibility
This cylinder liner set is specifically designed for Isuzu NPR66 trucks with 4HF1 engine.
Isuzu Truck Models:
  • ISUZU NPR66 (medium-duty truck, 4HF1 engine)
  • May also fit other Isuzu models using the 4HF1 engine (e.g., NPR59, NKR) - verify
Engine Specification - ISUZU 4HF1:
  • 4-Cylinder, Inline Diesel, Direct Injection
  • Displacement: 3.9L (3856cc)
  • Bore: 102 mm × 118 mm stroke
Installation Notes
Installation steps overview for wet liners (typical for 4HF1):
  1. Remove cylinder head, pistons, and old liners from block (use a liner puller)
  2. Clean block liner bores - remove rust, old O-ring residue, and debris
  3. Inspect block counterbores - check for damage or corrosion
  4. Install new O-rings onto the new liners (upper and lower seals)
  5. Lubricate O-rings and liner outer surface with clean engine oil or soapy water
  6. Press or drop new liners into the block bores - ensure they seat fully against the counterbore
  7. Measure liner protrusion above the block deck using a dial indicator and straight edge
  8. Hone the liners to final size (if needed) and to create a cross-hatch pattern
  9. Clean liners thoroughly - remove honing residue
  10. Install new pistons and rings, then cylinder head with new head gasket
  11. Fill coolant and check for leaks
Quality Control
  • Material Verification: Cast iron alloy composition and hardness tested
  • Dimensional Inspection: ID, OD, length, flange height, and concentricity verified
  • Surface Finish Test: Bore roughness (Ra) measured
  • Hydrostatic Test: Liners pressure-tested for porosity
  • Visual Inspection: 100% checked for casting defects or machining errors
  • Packaged Safely: Coated with anti-rust oil, individually wrapped, boxed as a set with foam
Packaging and Delivery
  • Neutral export packing or customized packaging available
  • Carton or wooden case for safe transportation
  • Fast delivery for stock items
  • Shipping by Express Air or Sea
Inquiry
For pricing, availability, or bulk purchase of the Cylinder Liner Set 5-87813332-0 For Isuzu NPR66 4HF1 Engine, please contact our sales team for a competitive quote and expert technical support.
