Front Engine Mount Rubber for ISUZU 4JJ1-T 3.0L Turbo Diesel with Vibration Damping and Natural Rubber/SBR Bonded to Steel
Front Engine Mount Rubber for ISUZU 4JJ1-T 3.0L Turbo Diesel with Vibration Damping and Natural Rubber/SBR Bonded to Steel
Front Engine Mount Rubber for ISUZU 4JJ1-T 3.0L Turbo Diesel with Vibration Damping and Natural Rubber/SBR Bonded to Steel
Front Engine Mount Rubber for ISUZU 4JJ1-T 3.0L Turbo Diesel with Vibration Damping and Natural Rubber/SBR Bonded to Steel
Front Engine Mount Rubber for ISUZU 4JJ1-T 3.0L Turbo Diesel with Vibration Damping and Natural Rubber/SBR Bonded to Steel
Front Engine Mount Rubber for ISUZU 4JJ1-T 3.0L Turbo Diesel with Vibration Damping and Natural Rubber/SBR Bonded to Steel
Front Engine Mount Rubber for ISUZU 4JJ1-T 3.0L Turbo Diesel with Vibration Damping and Natural Rubber/SBR Bonded to Steel
Front Engine Mount Rubber for ISUZU 4JJ1-T 3.0L Turbo Diesel with Vibration Damping and Natural Rubber/SBR Bonded to Steel
Front Engine Mount Rubber for ISUZU 4JJ1-T 3.0L Turbo Diesel with Vibration Damping and Natural Rubber/SBR Bonded to Steel
Front Engine Mount Rubber for ISUZU 4JJ1-T 3.0L Turbo Diesel with Vibration Damping and Natural Rubber/SBR Bonded to Steel
Specifications
Model Number :
ISUZU TFS85
Material :
Natural rubber / SBR bonded to steel
Brand Name :
YIMI
Part Name :
RUBBER; ENG FOOT, FRT
MOQ :
10 pcs
Delivery Time :
5-8 Work Days
Part No :
8-98043001-0, 8980430010
Payment Terms :
T/T,Western Union
Engine Displacement :
3.0L (2999cc)
Price :
Negotiable
Vehicle Model Code :
NKNPVK
Supply Ability :
10000 pcs/month
Bolt Torque :
40-60 Nm for chassis bolts, 50-70 Nm for engine bracket bolts
Certification :
ISO/TS16949
Engine Application :
ISUZU 4JJ1-T (3.0L Turbo Diesel)
Place of Origin :
China
Vehicle Applications :
ISUZU TFS85
Packaging Details :
Neutral Package or as customers’ request
Description
Front Engine Mount Rubber 8-98043001-0 For Isuzu TFS85 4JJ1-T
Function: Front engine mount rubber absorbs engine vibrations and isolates the powertrain from the chassis frame. Reduces noise, vibration, and harshness (NVH) for Isuzu 4JJ1-T diesel engines.
The Front Engine Mount Rubber (OEM Numbers: 8-98043001-0 / 8980430010) is a premium-quality, direct replacement engine mounting component designed for Isuzu TFS85 4WD pickups equipped with the 4JJ1-T turbo diesel engine.
Part Number: 8-98043001-0, 8980430010
Product Name: Front Engine Mount Rubber / Engine Foot / Engine Mount
Car Model: ISUZU TFS85
Engine Model: ISUZU 4JJ1-T (3.0L Turbo Diesel)
Condition: 100% Brand New
Warranty: 6 Months
Main Market: Middle East, Asia, Africa, South America, North America & Europe
Front Engine Mount Rubber for ISUZU 4JJ1-T 3.0L Turbo Diesel with Vibration Damping and Natural Rubber/SBR Bonded to Steel
Features & Advantages
  • OE Quality: Manufactured to Isuzu dimensional and material specifications for perfect fit and reliable vibration isolation
  • Premium Rubber Compound: Natural rubber/SBR blend resists oil, heat, and ozone
  • Steel Bonding: High-strength adhesive bonding prevents separation under load
  • Vibration Damping: Effectively absorbs engine vibrations, reducing cabin noise and driver fatigue
  • Corrosion Protected: Steel components are coated to resist rust
  • Restores Engine Alignment: Eliminates engine movement, clunking, and driveline vibration
  • Direct Replacement: Simple bolt-on installation using original hardware
  • Cost-Effective: Affordable alternative to genuine OEM mounts
Front Engine Mount Rubber for ISUZU 4JJ1-T 3.0L Turbo Diesel with Vibration Damping and Natural Rubber/SBR Bonded to Steel
Vehicle & Engine Compatibility
This front engine mount rubber is specifically designed for Isuzu TFS85 pickups with 4JJ1-T engine.
Isuzu Vehicle Models:
  • ISUZU TFS85 (4WD pickup, 4JJ1-T engine)
  • May also fit other Isuzu models with 4JJ1-T engine (e.g., D-MAX, MU-X) - verify compatibility
Engine Specification - ISUZU 4JJ1-T:
  • 4-Cylinder, Inline Diesel, DOHC, Turbocharged, Common Rail
  • Displacement: 3.0L (2999cc)
Installation Notes
Typical installation steps for front engine mount:
  1. Safely lift and support the vehicle. Use a jack to support the engine front (under oil pan with wooden block)
  2. Remove the old mount bolts (usually 2-4 bolts)
  3. Raise or lower the jack slightly to relieve pressure on the mount
  4. Remove the old front engine mount rubber
  5. Clean the mounting surfaces on the engine bracket and chassis frame
  6. Compare new mount with old (bolt hole alignment and height)
  7. Install the new mount, position the bracket, and hand-tighten bolts
  8. Adjust the jack to align the mount, then torque bolts to manufacturer specification
  9. Remove the jack and lower the vehicle
  10. Test drive - listen for clunks or excessive vibration
Quality Control
  • Material Verification: Rubber compound tested for hardness, tensile strength, and elongation
  • Bond Strength Test: Pull test ensures rubber-to-metal bond exceeds specification
  • Dimensional Inspection: Overall shape, mounting hole spacing, and height verified
  • Compression Set Test: Sample compressed at elevated temperature to ensure permanent deformation within limits
  • Aging Test: Accelerated heat aging to confirm retained elasticity
  • Visual Inspection: 100% checked for voids, cracks, flash, or missing rubber
  • Packaged Safely: Mount wrapped in plastic, boxed to prevent deformation
Packaging and Delivery
  • Neutral export packing or customized packaging available
  • Carton or wooden case for safe transportation
  • Fast delivery for stock items
  • Shipping by Express Air or Sea
Inquiry
For pricing, availability, or bulk purchase of the Front Engine Mount Rubber 8-98043001-0 For Isuzu TFS85 4JJ1-T, please contact our sales team for a competitive quote and expert technical support.
