Specifications
Engine Displacement :
3.0L (2999cc)
Place of Origin :
China
Model Number :
ISUZU NK, NM, NP, NKR77
Price :
Negotiable
Packaging Details :
Neutral Package or as customers’ request
Supply Ability :
10000 pcs/month
Delivery Time :
5-8 Work Days
Spline Count :
OEM specification
MOQ :
10 pcs
Construction :
Riveted
Material :
High-strength steel hub, organic/ceramic friction linings
Friction Material :
High-copper or organic linings
Payment Terms :
T/T,Western Union
Brand Name :
YIMI
Clutch Disc Diameter :
240mm or 250mm
Engine Type :
4-Cylinder, Inline Diesel, Turbocharged
Torque Bolt :
20-30 Nm for M8 bolts
Certification :
ISO/TS16949
Description
Clutch Disc 5-87610049-0 For Isuzu 4JH1 NKR77 NPR 8-97377149-0 Isuzu Truck Parts
The Clutch Disc (OEM Numbers: 5-87610049-0 / 5876100492, and 8-97377149-0 / 8973771490) is a premium-quality, direct replacement drivetrain component designed for Isuzu 4JH1 diesel engines, commonly used in Isuzu NKR77, NK, NM, NP series trucks.
Part Number: 5-87610049-0, 5876100492, 8-97377149-0, 8973771490
Product Name: Clutch Disc / Clutch Friction Disc
Car Model: ISUZU NK, NM, NP, NKR77
Engine Model: ISUZU 4JH1 (3.0L Turbo Diesel)
Condition: 100% Brand New
Origin: China Mainland
Warranty: 6 Months
Clutch Disc for Isuzu 4JH1 with High-Strength Steel Hub and Torsional Damper - Direct Replacement
Features & Advantages
  • OE Quality: Manufactured to Isuzu dimensional and performance specifications for perfect fit and reliable torque transmission
  • Torsional Damper: Multi-spring design absorbs vibrations, reducing gear noise and driveline shock
  • Premium Friction Material: High-copper or organic linings provide excellent heat dissipation and long wear life
  • Precision Splined Hub: Heat-treated for durability, ensures smooth sliding on input shaft
  • Riveted Construction: Securely bonded linings prevent delamination
  • Restores Clutch Performance: Eliminates slipping, judder, and hard shifting
  • Direct Replacement: Matches OE diameter and spline - simple installation
  • Cost-Effective: Affordable alternative to genuine OEM discs
Vehicle & Engine Compatibility
This clutch disc is specifically designed for Isuzu 4JH1 engines in various truck models.
Isuzu Truck Models:
  • ISUZU NKR77 (light-duty truck)
  • ISUZU NK, NM, NP series
  • May also fit other Isuzu light/medium trucks with 4JH1 engine - verify
Engine Specification - ISUZU 4JH1:
  • 4-Cylinder, Inline Diesel, Turbocharged
  • Displacement: 3.0L (2999cc)
Installation Notes
Installation steps (overview):
  1. Remove transmission and old clutch assembly
  2. Inspect and resurface flywheel
  3. Clean flywheel surface
  4. Install new clutch disc with alignment tool, centering on flywheel
  5. Install new pressure plate, torque bolts in a star pattern (20-30 Nm for M8 bolts)
  6. Remove alignment tool
  7. Install new release bearing and pilot bearing
  8. Reinstall transmission
  9. Test drive for smooth engagement
Quality Control
  • Material Verification: Friction material composition and hub steel grade tested
  • Dimensional Inspection: Outer diameter, spline ID/OD, disc thickness, and runout verified
  • Spline Fit Test: Each disc tested on a master input shaft
  • Friction Lining Shear Test: Rivet strength verified
  • Torsional Damper Test: Spring rate and angular deflection measured
  • Dynamic Balance Test: Disc balanced to minimize vibration
  • Visual Inspection: 100% checked for defects
  • Packaged Safely: Wrapped in anti-rust paper, boxed with foam
Packaging and Delivery
  • Neutral export packing or customized packaging available
  • Carton or wooden case for safe transportation
  • Fast delivery for stock items
  • Shipping by Express Air or Sea
For pricing, availability, or bulk purchase of the Clutch Disc 5-87610049-0 For Isuzu 4JH1 NKR77 NPR 8-97377149-0 Isuzu Truck Parts, please contact our sales team for a competitive quote and expert technical support.
