Premium-quality direct replacement glow plug designed for Isuzu TFR pickups with 3KB1 diesel engine. OEM Numbers: 8-94319700-4 / 8943197004 and 8-94144412-0 / 8941444120.

Pre-heats the combustion chamber to aid cold starting in diesel engines. Ensures reliable ignition and reduces white smoke for Isuzu TFR 3KB1 diesel engines.

• OE Quality: Manufactured to Isuzu dimensional and electrical specifications for perfect fit and reliable cold-start performance
• Fast Heat-Up: Rapid heating element provides quick pre-glow time
• High Temperature Resistance: Withstands extreme combustion temperatures without deformation
• Durable Construction: Sealed tip resists carbon fouling and corrosion
• Restores Cold Starting: Eliminates hard starting, white smoke, and misfire in cold weather
• Direct Replacement: Simple screw-in installation - matches OE thread and connector
• Cost-Effective: Affordable alternative to genuine Isuzu glow plugs

This glow plug is specifically designed for Isuzu TFR pickups with 3KB1 diesel engine.

• ISUZU TFR (pickup, 3KB1 engine)
• May also fit other Isuzu models with 3KB1 - verify compatibility

• 4-Cylinder, Inline Diesel
• Displacement: 2.5L (3KB1 engine family)

1. Disconnect battery negative cable
2. Remove the engine cover if necessary
3. Disconnect the electrical connector from the old glow plug
4. Use a deep socket to remove the old glow plug (apply penetrating oil if seized)
5. Clean the threads in the cylinder head using a thread chaser (do not use tap)
6. Apply a small amount of anti-seize to the threads of the new glow plug (avoid getting on tip)
7. Hand-thread the new glow plug, then torque to specification (typically 15-25 Nm). Do not overtighten
8. Reconnect the electrical connector
9. Repeat for all cylinders
10. Reconnect battery
11. Turn ignition to pre-heat position and check for proper function. Start engine and verify smooth idle

• Electrical Test: Resistance and heating time measured at rated voltage
• Temperature Test: Tip temperature verified within specification
• Dimensional Inspection: Thread size, overall length, and tip protrusion verified
• Visual Inspection: 100% checked for defects or damage
• Packaged Safely: Sealed in plastic bag, boxed with foam

• Neutral export packing or customized packaging available
• Carton or wooden case for safe transportation
• Fast delivery for stock items
• Shipping by Express Air or Sea

For pricing, availability, or bulk purchase of the Glow Plug 8-94319700-4 For Isuzu TFR 3KB1 Engine 8943197004 8941444120 Isuzu Truck Parts, please contact our sales team for a competitive quote and expert technical support.
