Front Engine Mount Rubber Natural Rubber/SBR Blend Steel Bonding Vibration Damping for Isuzu NHR54 4JA1
Front Engine Mount Rubber Natural Rubber/SBR Blend Steel Bonding Vibration Damping for Isuzu NHR54 4JA1
Front Engine Mount Rubber Natural Rubber/SBR Blend Steel Bonding Vibration Damping for Isuzu NHR54 4JA1
Front Engine Mount Rubber Natural Rubber/SBR Blend Steel Bonding Vibration Damping for Isuzu NHR54 4JA1
Front Engine Mount Rubber Natural Rubber/SBR Blend Steel Bonding Vibration Damping for Isuzu NHR54 4JA1
Front Engine Mount Rubber Natural Rubber/SBR Blend Steel Bonding Vibration Damping for Isuzu NHR54 4JA1
Front Engine Mount Rubber Natural Rubber/SBR Blend Steel Bonding Vibration Damping for Isuzu NHR54 4JA1
Front Engine Mount Rubber Natural Rubber/SBR Blend Steel Bonding Vibration Damping for Isuzu NHR54 4JA1
Front Engine Mount Rubber Natural Rubber/SBR Blend Steel Bonding Vibration Damping for Isuzu NHR54 4JA1
Front Engine Mount Rubber Natural Rubber/SBR Blend Steel Bonding Vibration Damping for Isuzu NHR54 4JA1
Specifications
Bolt Torque :
40-70 Nm
Part Number :
8-94155653-2, 8941556532
Engine Model :
ISUZU 4JA1 (2.5L Diesel)
Certification :
ISO/TS16949
Delivery Time :
5-8 Work Days
Compression Set :
Within limits
Bond Strength :
Exceeds specification
Supply Ability :
10000 pcs/month
Vehicle Model :
ISUZU NHR54
Brand Name :
YIMI
Price :
Negotiable
Payment Terms :
T/T,Western Union
Place of Origin :
China
MOQ :
10 pcs
Model Number :
ISUZU NHR54
Rubber Hardness :
Shore A
Packaging Details :
Neutral Package or as customers’ request
Material :
Natural rubber / SBR bonded to steel
Description
Front Engine Mount Rubber 8-94155653-2 For Isuzu NHR54 4JA1 8941556532 Isuzu Truck Parts

Function: Front engine mount rubber (engine foot) absorbs engine vibrations and isolates the powertrain from the chassis frame. Reduces noise, vibration, and harshness (NVH) for Isuzu NHR54 4JA1 diesel engines.

Part Number 8-94155653-2, 8941556532
Product Name Front Engine Mount Rubber / Engine Foot / Engine Mount
Car Model ISUZU NHR54
Engine Model ISUZU 4JA1 (2.5L Diesel)
Condition 100% Brand New
Origin China Mainland
Main Market Middle East, Asia, Africa, South America, North America & Europe
Warranty 6 Months
Front Engine Mount Rubber Natural Rubber/SBR Blend Steel Bonding Vibration Damping for Isuzu NHR54 4JA1
Features & Advantages
  • OE Quality: Manufactured to Isuzu dimensional and material specifications for perfect fit and reliable vibration isolation
  • Premium Rubber Compound: Natural rubber/SBR blend resists oil, heat, and ozone
  • Steel Bonding: High-strength adhesive bonding prevents separation under load
  • Vibration Damping: Effectively absorbs engine vibrations, reducing cabin noise and driver fatigue
  • Corrosion Protected: Steel components are coated to resist rust
  • Restores Engine Alignment: Eliminates engine movement, clunking, and driveline vibration
  • Direct Replacement: Simple bolt-on installation using original hardware
  • Cost-Effective: Affordable alternative to genuine OEM mounts
Front Engine Mount Rubber Natural Rubber/SBR Blend Steel Bonding Vibration Damping for Isuzu NHR54 4JA1
Vehicle & Engine Compatibility

This front engine mount rubber is specifically designed for Isuzu NHR54 trucks with 4JA1 engine.

Isuzu Truck Models:
  • ISUZU NHR54 (light-duty truck, 4JA1 engine)
  • May also fit other Isuzu light trucks with similar engine mounting - verify compatibility
Engine Specification - ISUZU 4JA1:
  • 4-Cylinder, Inline Diesel
  • Displacement: 2.5L (2499cc)
Installation Notes

Installation steps (typical for front engine mount):

  1. Safely lift and support the vehicle. Use a jack to support the engine front (under oil pan with wooden block)
  2. Remove the old mount bolts (usually 2-4 bolts)
  3. Raise or lower the jack slightly to relieve pressure on the mount
  4. Remove the old front engine mount rubber
  5. Clean the mounting surfaces on the engine bracket and chassis frame
  6. Compare new mount with old (bolt hole alignment and height)
  7. Install the new mount, position the bracket, and hand-tighten bolts
  8. Adjust the jack to align the mount, then torque bolts to manufacturer specification (typically 40-60 Nm for chassis bolts, 50-70 Nm for engine bracket bolts)
  9. Remove the jack and lower the vehicle
  10. Test drive - listen for clunks or excessive vibration
Quality Control
  • Material Verification: Rubber compound tested for hardness (Shore A), tensile strength, and elongation
  • Bond Strength Test: Pull test ensures rubber-to-metal bond exceeds specification
  • Dimensional Inspection: Overall shape, mounting hole spacing, and height verified
  • Compression Set Test: Sample compressed at elevated temperature to ensure permanent deformation within limits
  • Aging Test: Accelerated heat aging to confirm retained elasticity
  • Visual Inspection: 100% checked for voids, cracks, flash, or missing rubber
  • Packaged Safely: Mount wrapped in plastic, boxed to prevent deformation
Packaging and Delivery
  • Neutral export packing or customized packaging available
  • Carton or wooden case for safe transportation
  • Fast delivery for stock items
  • Shipping by Express Air or Sea
Inquiry

For pricing, availability, or bulk purchase of the Front Engine Mount Rubber 8-94155653-2 For Isuzu NHR54 4JA1 8941556532 Isuzu Truck Parts, please contact our sales team for a competitive quote and expert technical support.
