Nissan HR16DE 1.6L Engine Overhaul Gasket Kit with Multi-Layer Steel Cylinder Head Gasket and IATF 16949 Certification
Nissan HR16DE 1.6L Engine Overhaul Gasket Kit with Multi-Layer Steel Cylinder Head Gasket and IATF 16949 Certification
Specifications
Model Number :
Nissan HR16DE 1.6L Tiida Qashqai Micra
MOQ :
10 pcs
Payment Terms :
T/T,Western Union
Torque Output :
153 N·m (113 lb‑ft) at 4,400 rpm
Engine Compatibility :
Nissan HR16DE (1.6L / 1,598 cc inline‑4 petrol)
Power Output :
105–117 hp (78–87 kW) at 6,000 rpm
Place of Origin :
China
Packaging Details :
Neutral Package or as customers’ request
Cylinder Block Material :
Aluminum with cast‑iron liners
OEM Part Number :
10101-EE027 (also 10101EE027)
Bore × Stroke :
78.0 mm × 83.6 mm
Certification :
ISO/TS16949
Supply Ability :
10000 pcs/month
Brand Name :
YIMI
Cylinder Head Material :
Aluminum alloy
Price :
Negotiable
Compression Ratio :
9.8:1 to 10.7:1 (varies by market and tuning)
Delivery Time :
5-8 Work Days
Description
Engine Overhaul Gasket Kit 10101-EE027 For Nissan HR16DE 1.6L Tiida Qashqai Micra
Product Overview

The engine overhaul gasket kit (full gasket set / engine repair gasket set) carrying Nissan OEM number 10101-EE027 provides every sealing component required for a complete engine rebuild or top-end overhaul on the Nissan HR16DE 1.6L inline-4 petrol engine.

Nissan HR16DE 1.6L Engine Overhaul Gasket Kit with Multi-Layer Steel Cylinder Head Gasket and IATF 16949 Certification
Part Number:
10101-EE027
Product Name:
Engine Overhaul Gasket Kit
Car Model:
Nissan Tiida Qashqai Micra
Engine Model:
Nissan HR16DE 1.6L
Condition:
100% Brand New
Origin:
China Mainland
Main Market:
Middle East, Asia, Africa, South America, North America & Europe
Quality Standard:
OEM equivalent / ISO quality control
Kit Contents

10101-EE027 is a comprehensive full gasket set containing every sealing component required for a complete engine overhaul or top-end rebuild on the HR16DE:

Component Quantity / Notes
Cylinder head gasket 1 - MLS steel-laminate with elastomer coating, thickness matched to HR16DE piston protrusion
Valve cover gasket (rocker cover) 1 - with spark plug tube seals
Valve stem seals 16 pieces - Viton/fluoroelastomer, color-coded
Intake manifold gasket 1 - plastic intake plenum seal
Exhaust manifold gasket 1 - manifold-to-cylinder head seal
Oil pan gasket 1 - FIPG design or one-piece moulded rubber
Timing chain cover gaskets Full set - front cover seals and O-rings
Rear crankshaft seal 1 - oil seal at transmission flywheel interface
Camshaft seals 2 - front seals for intake and exhaust camshafts
Water pump gasket 1 - coolant pump mounting seal
Thermostat housing gasket 1 - outlet housing to cylinder head seal
Oil filter adapter gasket 1
O-ring sets Various - for coolant bypass pipe, oil dipstick tube, and other components
Fuel injector O-rings Set - 4 injector lower seals
Important Note

Cylinder head bolts are NOT included. The HR16DE uses torque-to-yield (stretch) cylinder head bolts that must be replaced whenever the cylinder head is removed. Order HR16DE cylinder head bolts separately.

Applications

This gasket kit directly replaces factory sealing components in the following vehicle configurations:

Model Series / Chassis Years Markets
Nissan Tiida (Hatchback) C11 2004-2012 Global
Nissan Qashqai / Qashqai+2 I J10, NJ10 2007-2013 Europe, Asia, Africa, Australia, Latin America
Nissan Micra K12, K13, K14 2005-2018 Europe, Japan, Asia, Latin America
Nissan Note I / Note II E11, E12 2005-2018 Europe, Japan, Asia
Nissan Versa / Versa Note N17 2007-2019 North America, Latin America
Nissan Juke F15 2010-2019 Global
Nissan Livina / Grand Livina L10, L11 2007-2019 Asia, Middle East
Nissan NV200 NV200 2009-2018 Global (commercial van / taxi)
Features & Benefits
  • Multi-Layer Steel (MLS) Cylinder Head Gasket - Designed for aluminium engines with stainless steel fire rings and elastomer coating
  • Complete Timing Chain Cover Gaskets - Includes all necessary seals for timing chain service
  • Full 16-Piece Valve Stem Seal Set - Color-coded for correct installation (intake vs exhaust)
  • Heat-Resistant Elastomer Seals - All O-rings and rubber gaskets manufactured from heat-resistant materials
  • IATF 16949 / ISO 9001 Certified Manufacturing - Highest automotive quality standards
  • Full OE Cross-Reference Coverage - Compatible with multiple OEM and aftermarket numbers
  • Prevents Common HR16DE Issues - Addresses valve cover seepage, timing cover seal failure, and exhaust manifold gasket deterioration
Quality Control
QC Item Verification Method
MLS head gasket fire ring alignment Laser measurement - 78.0 mm ±0.03 mm tolerance
Gasket thickness Digital micrometer verification against Nissan service spec
Valve stem seal inner diameter Precision air gauge - ±0.05 mm tolerance
Valve stem seal color coding 100% visual inspection
Camshaft seal lip integrity Optical inspection at 50× magnification
Elastomer material composition Certificate of analysis per batch
Full kit completeness 100% manual verification against HR16DE OE component list
Installation & Maintenance
⚠️ IMPORTANT

The HR16DE uses torque-to-yield (stretch) cylinder head bolts. These are single-use fasteners and must be replaced whenever the cylinder head is removed. Reusing old bolts risks uneven clamping, head gasket failure, and cylinder head warping.

Recommended Replacement Indicators
Symptom Diagnosis
Gradual coolant loss with no visible external leak Coolant escaping past head gasket into combustion chamber
White steam from exhaust on cold start Coolant burning in combustion chamber - head gasket failure
Bubbles in coolant overflow bottle with engine running Combustion gases entering cooling system
Pressurised cooling system (hoses rock-hard from cold) Combustion pressure entering cooling system
Milky residue under oil cap or on dipstick Coolant mixing with engine oil - internal head gasket failure
Blue smoke on start-up that clears after a few seconds Worn valve stem seals - oil seeping past valve guides
Oil misting around valve cover or timing cover Dried-out rocker cover gaskets or camshaft seals
Packaging & Supply
  • Individual packaging: Sealed in anti-static VCI bag, foam-lined carton
  • Carton dimensions: Approximately 55 × 40 × 5 cm
  • Net weight: Approximately 2.0-3.0 kg
  • Gross weight: 2.5-3.5 kg
  • Master carton: 10-20 units per export carton
  • Lead time: 3-7 working days for stock orders
  • Minimum order quantity: 1 piece
  • Shipping methods: FedEx, UPS, DHL for samples; sea freight for bulk
Quick Summary

The Nissan HR16DE engine overhaul gasket kit 10101-EE027 is a complete OE-spec sealing solution for 1.6L petrol engines in Tiida, Qashqai, Micra, Note, Versa, Juke, Livina, NV200, Cube, Sentra, Sylphy, Pulsar, and Latio vehicles from 2004 through 2018. The kit includes the MLS cylinder head gasket (78.0 mm bore), valve cover gasket, intake/exhaust manifold gaskets, oil pan gasket, timing chain cover gaskets, all 16 valve stem seals, and all associated O-rings.
