Rubber Bushing 8-97235784-0 for Isuzu D-MAX TFR Suspension with Vibration Damping, Noise Reduction, and Weather Resistant Properties
Rubber Bushing 8-97235784-0 for Isuzu D-MAX TFR Suspension with Vibration Damping, Noise Reduction, and Weather Resistant Properties
Rubber Bushing 8-97235784-0 for Isuzu D-MAX TFR Suspension with Vibration Damping, Noise Reduction, and Weather Resistant Properties
Rubber Bushing 8-97235784-0 for Isuzu D-MAX TFR Suspension with Vibration Damping, Noise Reduction, and Weather Resistant Properties
Rubber Bushing 8-97235784-0 for Isuzu D-MAX TFR Suspension with Vibration Damping, Noise Reduction, and Weather Resistant Properties
Rubber Bushing 8-97235784-0 for Isuzu D-MAX TFR Suspension with Vibration Damping, Noise Reduction, and Weather Resistant Properties
Rubber Bushing 8-97235784-0 for Isuzu D-MAX TFR Suspension with Vibration Damping, Noise Reduction, and Weather Resistant Properties
Rubber Bushing 8-97235784-0 for Isuzu D-MAX TFR Suspension with Vibration Damping, Noise Reduction, and Weather Resistant Properties
Specifications
Model Number :
ISUZU D-MAX, TFR
Material :
Natural rubber / SBR (synthetic rubber)
Brand Name :
YIMI
Part Name :
Rubber Bushing / Suspension Bushing
MOQ :
10 pcs
Delivery Time :
5-8 Work Days
Vehicle Model :
ISUZU D-MAX, TFR
Payment Terms :
T/T,Western Union
Installation :
Direct OEM replacement
Packaging Details :
Neutral Package or as customers’ request
Price :
Negotiable
Vehicle Model Code :
TF
Supply Ability :
10000 pcs/month
Quality Standard :
OEM equivalent / ISO quality control
Certification :
ISO/TS16949
Net Weight :
0.04 kg per piece
Place of Origin :
China
Part No :
8-97235784-0, 8972357840
Description
Rubber Bushing 8-97235784-0 For Isuzu D-MAX TFR Suspension 8972357840 Isuzu Spare Parts
Product Overview

Rubber suspension bushing isolates road vibrations, reduces metal-to-metal contact, and allows controlled articulation. Enhances ride comfort and handling for Isuzu D-MAX/TFR pickups.

Part Number 8-97235784-0, 8972357840
Product Name Rubber Bushing / Suspension Bushing
Car Model ISUZU D-MAX, TFR
Condition 100% Brand New
Origin China Mainland
Warranty 6 Months
Main Market Middle East, Asia, Africa, South America, North America & Europe
Rubber Bushing 8-97235784-0 for Isuzu D-MAX TFR Suspension with Vibration Damping, Noise Reduction, and Weather Resistant Properties
Features & Advantages
  • OE Quality: Manufactured to Isuzu dimensional and material specifications
  • Vibration Damping: Absorbs road shocks, reducing cabin noise and driver fatigue
  • Noise Reduction: Eliminates metal-to-metal contact, preventing clunks and squeaks
  • Weather Resistant: Rubber compound resists aging, ozone, and temperature extremes
  • Restores Handling: Eliminates play and restores proper suspension geometry
  • Direct Replacement: Simple press-in or bolt-on installation
  • Cost-Effective: Affordable alternative to genuine OEM bushings
Rubber Bushing 8-97235784-0 for Isuzu D-MAX TFR Suspension with Vibration Damping, Noise Reduction, and Weather Resistant Properties
Vehicle Compatibility

Isuzu Vehicle Models:

  • ISUZU D-MAX (various generations)
  • ISUZU TFR / TF Series (pickup)

Engine Compatibility: Not engine-specific - fits various engines (4JA1, 4JB1, 4JH1, 4JJ1, etc.)

Installation Notes

Installation steps (typical for suspension bushing):

  1. Safely lift and support the vehicle, remove the suspension arm or component
  2. Press out the old bushing using a suitable drift
  3. Clean the bushing bore
  4. Lubricate the new bushing outer sleeve with soapy water or rubber lubricant
  5. Press the new bushing into the bore, ensuring it is fully seated
  6. Reinstall the suspension arm and torque bolts to specification (with vehicle at ride height for rubber bushings)
  7. Perform wheel alignment if necessary
Quality Control
  • Material Verification: Rubber compound tested for hardness, tensile strength, and elongation
  • Dimensional Inspection: Inner/outer diameter, length, and profile verified
  • Compression Set Test: Sample compressed at elevated temperature to ensure permanent deformation within limits
  • Aging Test: Accelerated heat aging to confirm retained elasticity
  • Visual Inspection: 100% checked for voids, cracks, flash, or missing rubber
  • Packaged Safely: Bushings wrapped in plastic bag, boxed in sets of 5
Packaging and Delivery
  • Neutral export packing or customized packaging available
  • Carton or wooden case for safe transportation
  • Fast delivery for stock items
  • Shipping by Express Air or Sea

For pricing, availability, or bulk purchase of the Rubber Bushing 8-97235784-0 For Isuzu D-MAX TFR Suspension 8972357840 Isuzu Spare Parts, please contact our sales team for a competitive quote and expert technical support.
