Wet Type High-Alloy Cast Iron Cylinder Liner Kit OEM Standard for Isuzu NPR 4HF1 Engine
Wet Type High-Alloy Cast Iron Cylinder Liner Kit OEM Standard for Isuzu NPR 4HF1 Engine
Wet Type High-Alloy Cast Iron Cylinder Liner Kit OEM Standard for Isuzu NPR 4HF1 Engine
Wet Type High-Alloy Cast Iron Cylinder Liner Kit OEM Standard for Isuzu NPR 4HF1 Engine
Wet Type High-Alloy Cast Iron Cylinder Liner Kit OEM Standard for Isuzu NPR 4HF1 Engine
Wet Type High-Alloy Cast Iron Cylinder Liner Kit OEM Standard for Isuzu NPR 4HF1 Engine
Specifications
Place of Origin :
China
Payment Terms :
T/T,Western Union
Delivery Time :
5-8 Work Days
Brand Name :
YIMI
Model Number :
ISUZU NP4H
Part Number :
5-87811694-0, 5878116940
Cooling Type :
Engine coolant circulation
Bore Size :
102 mm
Liner Type :
Wet type (with O-rings)
Material :
High-alloy cast iron
Displacement :
3.9L (3856cc)
Supply Ability :
10000 pcs/month
Kit Components :
Cylinder liners, piston rings, retainers, gaskets, seals
Certification :
ISO/TS16949
Packaging Details :
Neutral Package or as customers’ request
MOQ :
10 pcs
Price :
Negotiable
Engine Model :
ISUZU 4HF1 (3.9L Diesel)
Description
Cylinder Liner Kit 5-87811694-0 For Isuzu NPR 4HF1 Engine 5878116940 Engine Cylinder Sleeve
Product Overview

The Cylinder Liner Kit (OEM Numbers: 5-87811694-0 / 5878116940) is a premium-quality, direct replacement engine component designed for Isuzu NPR medium-duty trucks equipped with the 4HF1 diesel engine (3.9L).

Part Number 5-87811694-0, 5878116940
Product Name CYLINDER LINER KIT
Car Model ISUZU NPR
Engine Model ISUZU 4HF1 (3.9L Diesel)
Condition 100% Brand New
Origin China Mainland
Warranty 6 Months
Wet Type High-Alloy Cast Iron Cylinder Liner Kit OEM Standard for Isuzu NPR 4HF1 Engine
Features & Advantages
  • OE Quality: Manufactured to Isuzu dimensional and material specifications
  • Complete Kit: Includes liners, piston rings, gaskets, and seals - all in one set
  • Precision Machined: Accurate bore size and surface finish for optimal ring sealing
  • Durable Cast Iron: Centrifugally cast for high strength and wear resistance
  • Restores Engine Performance: Eliminates blow-by, oil consumption, and power loss
  • Direct Replacement: Exact fit for 4HF1 engine block
Vehicle & Engine Compatibility

This cylinder liner kit is specifically designed for Isuzu NPR trucks with 4HF1 engine.

Isuzu Truck Models:
  • ISUZU NPR (NPR59, NPR66, NPR70, etc. with 4HF1)
Engine Specification - ISUZU 4HF1:
  • 4-Cylinder, Inline Diesel, Direct Injection
  • Displacement: 3.9L (3856cc)
  • Bore: 102 mm (typical)
Installation Notes

Professional engine machinist required. Installation process is complex:

  1. Engine disassembly - remove cylinder head, pistons, and old liners
  2. Clean block bores and inspect for damage
  3. Install new O-rings on liners
  4. Press or drop new liners into block, ensuring correct alignment
  5. Measure liner protrusion (adjust if needed)
  6. Hone liners to final finish
  7. Install new piston rings, retainers, gaskets, and seals
  8. Reassemble engine
Quality Control
  • Material Verification: Cast iron composition and hardness tested
  • Dimensional Inspection: ID, OD, length, flange height verified
  • Surface Finish: Plateau honed
  • Hydrostatic Test: Liners pressure-tested
  • Kit Completeness: All components counted and verified
Packaging and Delivery
  • Neutral export packing or customized packaging available
  • Carton or wooden case for safe transportation
  • Fast delivery for stock items
  • Shipping by Express Air or Sea

Inquiry: For pricing, availability, or bulk purchase of the Cylinder Liner Kit 5-87811694-0 For Isuzu NPR 4HF1 Engine 5878116940 Engine Cylinder Sleeve, please contact our sales team for a competitive quote and expert technical support.
