Specifications
Place of Origin :
China
Construction :
Steel frame + vulcanized rubber core
Packaging Details :
Neutral Package or as customers’ request
Rubber Material :
Natural rubber / Styrene Butadiene Rubber (SBR)
Steel Coating :
Corrosion-resistant e-coating / zinc plating
Brand Name :
YIMI
Payment Terms :
T/T,Western Union
Position :
Front mount (driver side)
Supply Ability :
3000 pcs/month
Price :
Negotiable
Mount Type :
Rubber-insulated steel mount
Weight :
4.5–5.0 kg
MOQ :
2 pcs
Certification :
ISO/TS16949
Delivery Time :
5-8 Work Days
OEM Part Numbers :
1‑53215184‑0, 1532151840
Model Number :
ISUZU FORWARD 800 1000
Engine Fitment :
6HH1 (6.6L), 6HK1 (7.8L), 6HE1 (7.2L), 6BG1
Description
Front Engine Mount 1-53215184-0 For ISUZU FORWARD 800 1000 — 1532151840 Rubber Insulator Heavy Duty Truck
The Front Engine Mount (Rubber Insulator / Cushion) with OEM number 1‑53215184‑0 (also listed as 1532151840) is a verified direct-fit replacement for the ISUZU FORWARD 800 and FORWARD 1000 series medium‑duty trucks.
Core Functions
  • Structural Support - Securely holds the engine in place within the chassis while allowing controlled movement under torque
  • Vibration Damping - Uses a composite of steel and rubber to absorb engine vibrations, preventing transmission to cabin and chassis
  • Noise Isolation - Reduces engine noise from reverberating through the vehicle structure
  • Protection of Ancillary Systems - Maintains proper engine alignment, reducing stress on driveline components
⚠️ Important Fitment Verification: The ISUZU FORWARD 800/1000 chassis can be equipped with various inline‑6 cylinder diesel engines. While mounting points are largely consistent, confirmation using your vehicle's chassis number / VIN is strongly recommended before ordering.
Technical Specifications
Parameter Specification
Part Name Front Engine Mount / Engine Foot Rubber / Insulator Mounting
OE Number(s) 1‑53215184‑0, 1532151840
Anchor Cross 8053 (Front Left / Driver Side)
Construction Steel frame + rubber cushion (bonded vulcanized construction)
Position Front mount (typically driver side / left side)
Application ISUZU FORWARD 800 series, FORWARD 1000 series
Engine Compatibility 6HH1 (6.6L), 6HK1 (7.8L), 6HE1 (7.2L), 6BG1 (6.5L) — verify by VIN
Material - Steel High‑grade steel with corrosion‑resistant coating
Material - Rubber Natural rubber / Styrene Butadiene Rubber (SBR)
Weight (approx.) 4-5 kg
Condition Brand New — 100% factory inspected
Certifications ISO 9001:2015, meets Isuzu OE specifications
Features & Benefits
Precision‑engineered steel frame
Securely supports heavy engine — withstands full weight of inline‑6 diesel engine plus dynamic torque loads
Premium natural/SBR rubber core
Superior vibration damping — optimal balance of stiffness and compliance
Corrosion‑resistant e‑coating
Long service life in harsh environments — resists road salt, moisture, and chemical exposure
Direct OE replacement fitment
Simplified replacement — identical bolt hole spacing, stud positions, and insulator height
Failure Symptoms & Replacement Indicators
Symptom Diagnosis
Excessive engine vibration at idle Pronounced shaking through floor, steering wheel, or dashboard when stationary
Clunking / banging noise When accelerating, shifting gears, or going over bumps
Transmission / driveline stress Engine sag misaligns transmission output shaft with driveshaft
Visual degradation of rubber Cracks, dry rot, surface checking, oil saturation, or complete separation
High mileage (>400,000‑500,000 km) Rubber hardens and loses elasticity over time — preventive replacement recommended
Installation Recommendations
⚠️ IMPORTANT: Engine mount replacement on heavy trucks requires engine lifting / support. Professional installation by qualified heavy vehicle mechanics is strongly recommended.
Tools required: Heavy‑duty engine support bar, torque wrench, socket set, penetrating oil, jack stands, personal protective equipment
Maintenance Schedule
Maintenance Item Interval Notes
Visual inspection of engine mounts Every 50,000‑80,000 km Check for cracks, oil saturation, separation
Rubber hardness check Every 200,000 km Hardened rubber should be replaced
Engine mount replacement (preventive) Every 400,000‑500,000 km Or when any symptom appears
Replace as set When replacing one front mount Replace opposite side and inspect rear mount
Inquiry & Ordering Information
For Front Engine Mount 1‑53215184‑0 / 1532151840 — OE Rubber Insulator for ISUZU FORWARD 800 & FORWARD 1000 series:
  • Wholesale prices for fleets, repair shops, distributors
  • Single unit sample available for fitment verification
  • Bulk order discounts & custom export packaging
  • QC report & ISO 9001:2015 certification on request
  • Replacement sets available (left + right front mounts)
Please provide your quantity, destination port, and vehicle specifics (ISUZU model, engine code, chassis number/VIN) for accurate fitment verification.
