Water Pump Assembly with High-Efficiency Impeller and Corrosion-Resistant Treatment for ISUZU 6BD1 Engine
Water Pump Assembly with High-Efficiency Impeller and Corrosion-Resistant Treatment for ISUZU 6BD1 Engine
Water Pump Assembly with High-Efficiency Impeller and Corrosion-Resistant Treatment for ISUZU 6BD1 Engine
Water Pump Assembly with High-Efficiency Impeller and Corrosion-Resistant Treatment for ISUZU 6BD1 Engine
Water Pump Assembly with High-Efficiency Impeller and Corrosion-Resistant Treatment for ISUZU 6BD1 Engine
Water Pump Assembly with High-Efficiency Impeller and Corrosion-Resistant Treatment for ISUZU 6BD1 Engine
Water Pump Assembly with High-Efficiency Impeller and Corrosion-Resistant Treatment for ISUZU 6BD1 Engine
Water Pump Assembly with High-Efficiency Impeller and Corrosion-Resistant Treatment for ISUZU 6BD1 Engine
Specifications
Payment Terms :
T/T,
Cooling Type :
Engine coolant circulation
Model Number :
ISUZU FSR113, FTR, HTS, HTW, FSS, FSD Series
Part No :
1136108190, 1-13610819-0
MOQ :
10 pcs
Delivery Time :
5-8 Work Days
Drive Type :
Belt-Driven
Price :
Negotiable
Bearings :
Premium-Quality, Sealed Bearings
Certifiion :
ISO/TS16949
Impeller Type :
High-Efficiency Impeller
Supply Ability :
10000 pcs/month
Displacement :
5.8L
Brand Name :
YIMI
Material :
High-Grade Cast Housing with Corrosion-Resistant Treatment
Packaging Details :
Neutral Package or as customers’ request
Place of Origin :
China
Engine Appliion :
ISUZU 6BD1 Diesel Engine (5.8L)
Description
Water Pump Assembly 1136108190 For ISUZU FSR113 6BD1 Engine

Precision-engineered water pump circulates coolant through the engine and radiator, maintaining optimal operating temperature for reliable performance in ISUZU 6BD1 diesel engines.

Part Number 1136108190, 1-13610819-0
Product Name Water Pump Assembly / Engine Water Pump
Car Model ISUZU FSR113, FTR, HTS, HTW, FSS, FSD Series
Engine Model ISUZU 6BD1 Diesel Engine (5.8L)
Condition 100% Brand New
Origin China Mainland
Main Market Middle East, Asia, Africa, South America, North America & Europe
Warranty 6 Months
Water Pump Assembly with High-Efficiency Impeller and Corrosion-Resistant Treatment for ISUZU 6BD1 Engine
Features & Advantages
  • OE Quality: Manufactured to strict ISUZU dimensional and material specifiions for perfect fit and function
  • Precision Cast Housing: Corrosion-resistant construction ensures long service life
  • High-Efficiency Impeller: Delivers consistent coolant flow for optimal temperature regulation
  • Premium Bearings: Sealed bearing design provides smooth, reliable operation
  • Durable Shaft: Robust shaft construction withstands continuous operation
  • Leak-Proof Design: Precision sealing prevents coolant leakage
  • Restores Cooling Efficiency: Eliminates overheating caused by worn or damaged pumps
  • Protects the Engine: Prevents thermal stress and astrophic engine damage
  • Direct Replacement: Simple installation during cooling system service
  • Long Service Life: Engineered for reliability in demanding commercial appliions
  • Cost-Effective: Essential component for engine protection and reliability
Water Pump Assembly with High-Efficiency Impeller and Corrosion-Resistant Treatment for ISUZU 6BD1 Engine
Vehicle & Engine Compatibility

This water pump assembly is specifically designed for ISUZU medium-duty trucks. Common appliions include:

  • ISUZU FSR113 – Medium-Duty Trucks
  • ISUZU FTR – Medium-Duty Trucks
  • ISUZU HTS – Medium-Duty Trucks
  • ISUZU HTW – Medium-Duty Trucks
  • ISUZU FSS – Medium-Duty Trucks
  • ISUZU FSD – Medium-Duty Trucks
  • ISUZU FSR – Various models with 6BD1 engine

ISUZU 6BD1 Engine Specifiions:

  • 6-Cylinder, Inline Diesel
  • Displacement: 5.8L
  • Valvetrain: OHV
  • Widely used in F-series medium-duty trucks
Installation Notes
Professional installation recommended. Proper cooling system service is critical for optimal performance and engine protection.
  1. Allow engine to cool – Ensure the engine is completely cool before beginning work
  2. Disconnect battery – Disconnect the negative battery cable before beginning work
  3. Drain coolant – Drain the cooling system completely
  4. Remove the drive belt – Loosen and remove the drive belt from the water pump pulley
  5. Remove the fan shroud and fan – Remove the fan and shroud for access to the water pump
  6. Remove the old water pump – Unbolt and carefully remove the water pump from the engine block
  7. Remove old gasket material – Clean the engine block mounting surface, removing all old gasket material
  8. Inspect the cooling system – Check the thermostat, hoses, and radiator for wear or damage
  9. Clean mounting surface – Thoroughly clean the engine block mounting surface
  10. Prepare the new pump – Inspect the new pump and verify it matches the original
  11. Install the new gasket – Position a new gasket on the engine block
  12. Install the new water pump – Position the new pump and secure with mounting bolts
  13. Torque to specifiion – Tighten bolts to manufacturer specifiion in a crisscross pattern
  14. Reinstall fan and shroud – Reinstall the fan, shroud, and drive belt
  15. Adjust belt tension – Adjust the drive belt tension to manufacturer specifiion
  16. Refill coolant – Refill the cooling system with the correct type and mixture of coolant
  17. Bleed air from the system – Bleed air from the cooling system as per the service manual
  18. Reconnect battery – Reconnect the negative battery cable
  19. Check for leaks – Start the engine and inspect for any coolant leakage around the pump
  20. Verify operation – Allow the engine to reach operating temperature and verify proper cooling system operation
Quality Control
  • Material Verifiion: Confirms housing and internal component materials meet OE specifiions
  • Dimensional Inspection: Mounting points, impeller dimensions, and shaft positions verified against OEM tolerances
  • Impeller Balance Testing: Impeller dynamically balanced for smooth, vibration-free operation
  • Bearing Quality Testing: Bearing smoothness and durability verified
  • Leak Testing: 100% pressure-tested to ensure leak-proof performance
  • Flow Rate Testing: Coolant flow capacity verified to OE requirements
  • Visual Inspection: 100% checked for casting defects, machining flaws, or damage
  • Packaged Safely: Protected and securely boxed to prevent damage during transit
Packaging and Delivery
  • Neutral export packing or customized packaging available
  • Carton or wooden case for safe transportation
  • Fast delivery for stock items
  • Shipping by Express Air or Sea
Inquiry

For pricing, availability, or bulk purchase of the Water Pump Assembly 1136108190 For ISUZU FSR113 6BD1 Engine 1-13610819-0, please contact our sales team for a competitive quote and expert technical support.
