High-alloy cast iron Piston Liner Kit for Isuzu 4BE1 Engine - Direct OEM replacement with complete pistons and rings
High-alloy cast iron Piston Liner Kit for Isuzu 4BE1 Engine - Direct OEM replacement with complete pistons and rings
High-alloy cast iron Piston Liner Kit for Isuzu 4BE1 Engine - Direct OEM replacement with complete pistons and rings
High-alloy cast iron Piston Liner Kit for Isuzu 4BE1 Engine - Direct OEM replacement with complete pistons and rings
High-alloy cast iron Piston Liner Kit for Isuzu 4BE1 Engine - Direct OEM replacement with complete pistons and rings
High-alloy cast iron Piston Liner Kit for Isuzu 4BE1 Engine - Direct OEM replacement with complete pistons and rings
Specifications
Model Number :
ISUZU
Part Number :
8-94438989-1, 8944389891
MOQ :
10 pcs
Delivery Time :
5-8 Work Days
Displacement :
3.6L (3636cc)
Price :
Negotiable
Bore Size :
Approx. 102mm
Certifiion :
ISO/TS16949
Kit Components :
Cylinder liners, pistons, piston rings, pins, seals (full set)
Payment Terms :
T/T,
Cooling Type :
Engine coolant circulation
Supply Ability :
10000 pcs/month
Installation Type :
Direct OEM replacement
Brand Name :
YIMI
Material :
High-alloy cast iron (liners), aluminum alloy (pistons), steel (rings)
Packaging Details :
Neutral Package or as customers’ request
Place of Origin :
China
Engine Model :
ISUZU 4BE1 (3.6L Diesel)
Description
Piston Liner Kit 8-94438989-1 For Isuzu 4BE1 Engine
This premium piston liner kit provides a durable, replaceable wear surface for piston rings, restoring compression, reducing oil consumption, and extending engine life for Isuzu 4BE1 diesel engines.
Part Number 8-94438989-1, 8944389891
Product Name Engine Piston / Piston Liner Kit
Car Model ISUZU
Engine Model ISUZU 4BE1 (3.6L Diesel)
Condition 100% Brand New
Material High-strength aluminum alloy & precision bearings
Warranty 6 Months
High-alloy cast iron Piston Liner Kit for Isuzu 4BE1 Engine - Direct OEM replacement with complete pistons and rings
Features & Advantages
  • OE Quality: Manufactured to Isuzu dimensional and material specifiions for perfect fit and long service life
  • Complete Kit: Includes liners, pistons, rings, and seals - all in one set
  • Precision Machined: Accurate bore size and surface finish for optimal ring sealing
  • Durable Cast Iron Liners: Centrifugally cast for high strength and wear resistance
  • High-Quality Pistons: Aluminum alloy with precision ring grooves
  • Piston Rings Included: Compression and oil rings provide proper sealing and oil control
  • Restores Engine Performance: Eliminates blow-by, oil consumption, and power loss
  • Direct Replacement: Exact fit for 4BE1 engine block
High-alloy cast iron Piston Liner Kit for Isuzu 4BE1 Engine - Direct OEM replacement with complete pistons and rings
Vehicle & Engine Compatibility
This piston liner kit is specifically designed for Isuzu 4BE1 engines.
Isuzu Vehicle Models:
  • ISUZU NPR58 (medium-duty truck)
  • ISUZU NPR59 (medium-duty truck)
  • ISUZU NKR (light-duty truck)
  • ISUZU ELF (Japanese market)
  • Industrial equipment (generators, compressors, etc.)
Engine Specifiion - ISUZU 4BE1:
  • 4-Cylinder, Inline Diesel
  • Displacement: 3.6L (3636cc)
  • Bore: Approx. 102mm (verify)
Installation Notes
Professional engine machinist required. Installation process requires precision:
  1. Engine disassembly - remove cylinder head, pistons, and old liners
  2. Clean block bores and inspect for damage
  3. Install new O-rings on liners
  4. Press or drop new liners into block, ensuring correct alignment
  5. Measure liner protrusion (adjust if needed)
  6. Hone liners to final finish
  7. Install new pistons with new rings onto connecting rods
  8. Lubrie and install piston/ring assemblies into cylinders
  9. Install new gaskets and seals
  10. Reassemble engine
Quality Control
  • Material Verifiion: Liner cast iron, piston alloy, and ring steel composition tested
  • Dimensional Inspection: Bore size, piston diameter, and ring gaps verified
  • Surface Finish: Liners plateau honed
  • Hydrostatic Test: Liners pressure-tested
  • Kit Completeness: All components counted and verified
  • Visual Inspection: 100% checked for defects
Packaging and Delivery
  • Neutral export packing or customized packaging available
  • Carton or wooden case for safe transportation
  • Fast delivery for stock items
  • Shipping by Express Air or Sea
Inquiry
For pricing, availability, or bulk purchase of the Piston Liner Kit 8-94438989-1 For Isuzu 4BE1 Engine 8944389891 Isuzu Engine Parts, please contact our sales team for a competitive quote and expert technical support.
