The Tie Rod End with OEM number 1-43150857-0 (without hyphen 1431508570) is a verified direct-fit replacement for ISUZU CXZ series commercial vehicles equipped with the 6WF1 engine, widely used in pump trucks, mixer trucks, and other heavy-duty construction vehicles.

This steering tie rod end is a critical safety component that connects the tie rod to the steering knuckle arm, transmitting steering force from the steering gear to the wheel while allowing suspension movement through its ball-joint design.

• OEM Drawing Dimension Verification: Manufactured to ISUZU OEM drawings and sample dimensions
• Material & Heat Treatment Verification: Alloy steel construction with forging, quenching and tempering
• Ball Joint Performance Verification: Ball joint swing torque, axial clearance, and pull-out strength testing
• Thread Accuracy Verification: Threads inspected with go/no-go gauges
• OEM Cross-Reference Verified: Replaces 1-43150857-0 / 1431508570

• Excessive steering play: noticeably increased steering wheel free play
• Vehicle pulling: continuous drift to one side
• Abnormal front tire wear: uneven, scalloped, or excessive tire wear
• Steering noise: metallic clunking over bumps or during steering
• Broken dust boot / grease leakage: cracked boot and dirt ingress
• Loose ball joint: noticeable play when shaking the tire

1. Lift and safely support the vehicle; remove the wheel
2. Remove the old tie rod end lock nut, cotter pin, and connecting nut
3. Use a dedicated puller to separate the ball joint from the steering knuckle arm
4. Clean the taper hole and threads; inspect the steering knuckle taper for wear
5. Install the new tie rod end; tighten the connecting nut to specified torque
6. Adjust toe and tighten the tie rod lock nut
7. Perform four-wheel alignment and road test

• Inspect the dust boot for cracks and grease leakage at every service
• Check steering play every 10,000–20,000 km or per fleet maintenance schedule
• Replace immediately if noise, play, or pulling is detected

• Neutral carton/wooden case packaging with individual anti-rust bag
• Custom branded packaging available (authorization required)
• Suitable for: ISUZU truck repair shops, construction vehicle parts wholesalers, fleet maintenance departments
• MOQ: Please contact for confirmation
