Precision-engineered right outer tie rod end transmits steering input from the rack to the steering knuckle, ensuring precise directional control and responsive handling for Mazda vehicles.

The Tie Rod End (OEM Numbers: BP4L32280 / BP4L-32-280 / BP4L 32 280 / BP4L-32280) is a premium-quality, direct replacement steering component designed for Mazda 3 (BK/BL), Mazda 5 (CR/CW), Mazdaspeed3, and Ford Focus II models. This right outer tie rod end is a critical linkage component in the vehicle's steering system, responsible for transmitting steering input from the steering rack to the steering knuckle, enabling precise directional control, responsive handling, and proper wheel alignment.

• OE Quality: Manufactured to strict Mazda dimensional and strength specifications for perfect fit and function
• Heavy-Duty Forged Steel: Provides exceptional strength and durability under severe steering loads
• Precision Threading: M17x1.5 internal and M10x1.25 external threads ensure secure installation
• Corrosion-Resistant Coating: Black coating protects against rust and environmental damage
• Direct Replacement: Exact fit for Mazda 3 and 5 models with no modifications required
• Restores Steering Precision: Eliminates steering wander and loose feel caused by worn tie rod ends
• Improves Handling: Provides responsive, precise vehicle control
• Prevents Uneven Tire Wear: Correct steering geometry extends tire life
• Critical Safety Component: Ensures reliable steering operation
• Long Service Life: Engineered to withstand the rigors of daily driving

This tie rod end is specifically designed for Mazda and compatible vehicles. Common applications include:

• Mazda 3 (BK) — 2004-2009
• Mazda 3 (BL) — 2010-2013
• Mazda 5 (CR) — 2006-2010
• Mazda 5 (CW) — 2012-2015
• Mazdaspeed3 — 2007-2013

• 2.0L L4 — Gasoline
• 2.3L L4 — Gasoline
• 2.5L L4 — Gasoline

• Ford Focus II — 2005-2009

1. Raise and secure the vehicle — Safely raise the front of the vehicle and support on jack stands
2. Remove the front wheel — Remove the front wheel for access to steering components
3. Remove the old tie rod end — Loosen the jam nut and disconnect the tie rod end from the steering knuckle
4. Mark or measure settings — Note the position of the old tie rod end for reference (count exposed threads)
5. Inspect related components — Check the steering rack, inner tie rod, and other steering components for wear; replace as needed
6. Clean mounting area — Clean the steering knuckle taper hole and tie rod threads
7. Prepare the new tie rod end — Inspect the new component and verify it matches the original
8. Install the new tie rod end — Thread the new tie rod end into the inner tie rod, matching the old setting
9. Connect to steering knuckle — Insert the taper stud into the steering knuckle and install the nut
10. Torque to specification — Torque the nut to manufacturer specification
11. Install cotter pin — Install a new cotter pin to secure the nut
12. Tighten jam nut — Tighten the jam nut to manufacturer specification
13. Reinstall the wheel — Reinstall the wheel and torque lug nuts to specification
14. Lower the vehicle — Lower the vehicle to the ground
15. Check steering operation — Turn the steering wheel lock-to-lock to check for smooth operation
16. Perform wheel alignment — Professional wheel alignment (toe-in adjustment) is mandatory
17. Road test — Test drive the vehicle to verify straight-line stability and responsive steering

• Material Verification: Confirms forged steel composition meets OE strength specifications
• Dimensional Inspection: Thread sizes, length (108mm), and cone size (12.2mm) verified against OEM tolerances
• Thread Inspection: M17x1.5 and M10x1.25 threads verified to specifications
• Hardness Testing: Material hardness verified for wear resistance and durability
• Surface Finish Inspection: Coating quality and corrosion resistance verified
• Visual Inspection: 100% checked for forging defects, cracks, or surface flaws
• Packaged Safely: Protected and securely packaged to prevent damage during transit

• Neutral export packing or customized packaging available
• Carton or wooden case for safe transportation
• Fast delivery for stock items
• Shipping by Express Air or Sea

For pricing, availability, or bulk purchase of the Tie Rod End BP4L32280 For Mazda 3 5 2004-2015 Right Outer Steering BP4L-32-280, please contact our sales team for a competitive quote and expert technical support.
