Specifications
Brand Name :
Shi Zun
Model Number :
ASK8721E
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Supply Ability :
100+pcs+day
Delivery Time :
10 working days
Packaging Details :
115* 75* 21 (mm)
Payment Terms :
T/T
Networking :
Ethernet/ WIFI
Opening Methods :
QR Code/IC Card/ CPU Card/ ID Card/ Mobile NFC/ Bluetooth
USB type :
USB2.0x2
power supply :
DC 12 volts 3 A, aperture 5 mm
earphone :
20 mW @ 16 ohm, stereo, 3.5 mm diameter headphone jack
Origin :
China
Communication Protocols :
HTTP, MQTT, TCP/IP for cloud platform management, remote management via mini programs
Processor :
Xtensa 32-bit LX6 dual-core processor, with a main frequency of 600 MIPS
Operating System :
FreeRTOS embedded system
Recognition Support :
QR Code, Bluetooth, IC Card, CPU Card, NFC
Protocol Support :
HTTP, MQTT, TCP/IP
External Interfaces :
Dry contact output, exit button input, door magnet input
Supported QR Code Formats :
PDF417/Data Matrix/QR Code
Code Reading Angle :
Elevation and Tilt ±65°, Rotation 360°
Scanning Angle :
Horizontal 75°, Vertical 55°, Diagonal 85°
Reading Speed :
Less than 0.2 seconds
Scanning Distance :
5-15 cm
Interaction Methods :
Buzzer, 2.8-inch LCD display
Input Voltage :
DC12V/500mA (Supports 5-30V)
Bluetooth Version :
BLE 4.1
User Storage :
60,000 users
Waterproof Level :
IPX65
Tempered Glass Panel :
9H
Operating Environment: Temperature :
-20°C to 70°C, Humidity 5%-95%
Product Dimensions :
115* 75* 21 (mm)
Product Weight :
160g
Description

SK87E QR Code Access Control Integrated Machine Buzzer, 2.8-inch LCD display Interaction Methods

SK87E Qr Code Access Control Device Description:

  1. Network Options: Ethernet / WIFI
  2. Access Methods: QR Code / IC Card/CPU Card / ID Card/Mobile NFC / Bluetooth
  3. Communication Protocols: HTTP, MQTT, TCP/IP; Cloud Platform Management, Mini Program Remote Management
  4. Features: Remote Access, Customizable Anti-Copying, Custom Voice Playback, Screen UI customization
  5. Supports Secondary Development for Third-Party Platform Integration
  6. Material: Tempered Glass Panel / Metal Casing / Waterproof

SK86GK Qr Code Access Control Device Parameters:

Processor Xtensa 32-bit LX6 dual-core processor, with a main frequency of 600 MIPS
Operating System FreeRTOS Embedded System
Recognition Support QR Code, Bluetooth, IC Card, CPU Card, NFC
Protocol Support HTTP, MQTT, TCP/IP
External Interfaces Dry Contact Output, Exit Button Input, Door Sensor Input
Supported QR Code Formats PDF417 / Data Matrix / QR Code
Code Reading Angle Elevation and Tilt ±65°, Rotation 360°
Scanning Angles Horizontal 75°, Vertical 55°, Diagonal 85°
Reading Speed <0.2 seconds
Interaction Methods Buzzer, 2.8-inch LCD display
