45-480V 150-6000W Fast Response Time Short Wave IR Lamp Halogen Quartz Lamp Tube Infrared Heating Element Tube
45-480V 150-6000W Fast Response Time Short Wave IR Lamp Halogen Quartz Lamp Tube Infrared Heating Element Tube
45-480V 150-6000W Fast Response Time Short Wave IR Lamp Halogen Quartz Lamp Tube Infrared Heating Element Tube
45-480V 150-6000W Fast Response Time Short Wave IR Lamp Halogen Quartz Lamp Tube Infrared Heating Element Tube
45-480V 150-6000W Fast Response Time Short Wave IR Lamp Halogen Quartz Lamp Tube Infrared Heating Element Tube
45-480V 150-6000W Fast Response Time Short Wave IR Lamp Halogen Quartz Lamp Tube Infrared Heating Element Tube
45-480V 150-6000W Fast Response Time Short Wave IR Lamp Halogen Quartz Lamp Tube Infrared Heating Element Tube
45-480V 150-6000W Fast Response Time Short Wave IR Lamp Halogen Quartz Lamp Tube Infrared Heating Element Tube
Specifications
Brand Name :
UVIR
Certification :
CE & ROHS
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,MoneyGram,Western Union
Delivery Time :
15-20 Work day
Packaging Details :
Each lamp in a cylinder .Then in a professional plywood box
Model Number :
SHG300948
Name: :
3d halogen heating tube emitter lamp
Specification: :
Short wave infrared lamp
Voltage: :
45-480V
Customized: :
Yes,according to your requirement
Filament temp.: :
1600-2600
Color: :
transparent
Power： :
150-6000W
Description
single tube short wave ir halogen quartz lamp tube white coating infrared emitters
Product Specifications
Attribute Value
Name 3d halogen heating tube emitter lamp
Specification Short wave infrared lamp
Voltage 45-480V
Customized Yes, according to your requirement
Filament temperature 1600-2600
Color Transparent
Power 150-6000W
Key Advantages
  • Can switch on and off frequently
  • 1~2 seconds fast response time to full power heating
  • Output power adjustable via voltage regulator (0V~rated voltage)
  • Precise (±1℃) temperature control with SCR regulator
  • Compact design with flexible horizontal/vertical installation
  • Suitable for industrial applications up to 1000℃
  • Gold reflector (90% reflective) and Nano-ceramic reflector (70% reflective) options
  • Customizable IR wavelengths for different applications
  • High power density output up to 200KW/M²
  • 5000 hours average working life guarantee
Product Description
Heatelement Twin-Tube infrared lamps are manufactured from high-quality fused quartz tubes with gold reflector for maximum efficiency. The unique design provides higher radiation density, improved mechanical stability, and better focus. Available as short-wave, medium-wave and fast response medium-wave infrared emitters to match specific material heating requirements.
Product Name Infrared Lamp
Type 3D infrared lamp
Application Heating applications
Light source Tungsten filament
Material Quartz Tube
OEM/ODM Custom voltage, wattage, length, base, cables, and universal burning position available

45-480V 150-6000W Fast Response Time Short Wave IR Lamp Halogen Quartz Lamp Tube Infrared Heating Element Tube

45-480V 150-6000W Fast Response Time Short Wave IR Lamp Halogen Quartz Lamp Tube Infrared Heating Element Tube
Available Parameters
115 410 10 SHG300169 SHW300001 SHC300002 280770
115 510 10 SHG300049 SHW300002 SHC300003 284343
115 520 10 SHG300043 SHW300003 SHC300004 282094
115 600 10 SHG300050 SHW300004 SHC300005 282016
115 710 10 SHG300164 SHW300005 SHC300006 282014
115 1100 10 SHG300165 SHW300006 SHC300007 283932
115 1100 11x23 THG300039 THW300001 THC100001 282002
115 1320 10 SHG300037 SHW300007 SHC300008 280773
Contact us for custom parameters. Our professional team can provide technical expertise and drawings for your specific requirements.
Industrial Applications
  • Plastics Processing: IR drying, stretching/shrinking, blow molding
  • Photovoltaic Industry: String soldering, sputtering preheating
  • Printing Industry: Ink curing, drying for banners and plates
  • Food & Chemical: Disinfection, food heating, herbal medicine processing
  • Glass Industry: Preheating, coating drying, laminated glass
  • Textiles: Fabric coating drying and laminating
  • Electronics: Component coating and aging processes
Frequently Asked Questions
Q1. Can I have a sample order?
A: Yes, we welcome sample orders to test quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: Samples take 5-7 days, mass production about 30 days.
Q3. Do you have any MOQ limit?
A: Minimum order quantity is typically 2 pieces per model.
Q4. How do you ship the goods?
A: Samples via DHL/UPS/FedEx/TNT; bulk orders via air or sea freight.
Q5. How to proceed an order?
A: 1) Share requirements 2) Receive quote 3) Approve samples 4) Place deposit 5) Production begins.
Q6. How to deal with faulty products?
A: All products undergo strict quality control. During warranty, replacements are included in next order.
